Product Description
Intel Core i7-13700 (30MB Cache), 32GB DDR5-SDRAM, 2000GB SSD, Intel UHD Graphics 770, NVIDIA Quadro T1000 (8GB GDDR6), LAN, Windows 11 Pro 64-bit
Features
- Mini PC Black 300 W
- Intel® Core™ i7 i7-13700
- 32 GB DDR5-SDRAM 4800 MHz 2 x 16 GB
- 2 TB SSD
- NVIDIA Quadro T1000 8 GB Intel UHD Graphics 770
- Ethernet LAN 10,100,1000 Mbit/s
- Windows 11 Pro 64-bit
Product Videos
Specifications
| Spec | Description |
|---|---|
| Audio chip | Realtek ALC256-VB |
| Bluetooth | No |
| Built-in speaker(s) | Yes |
| Bus type | DMI4 |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Cabling technology | 10/100/1000Base-T(X) |
| Card reader integrated | No |
| Certification | EPEAT Gold Registered ENERGY STAR 8.0 ErP Lot 3 TCO Certified 9.0 RoHS compliant MIL-STD-810H |
| Chassis type | Mini PC |
| Combo headphone/mic port | Yes |
| CPU configuration (max) | 1 |
| Depth | 182.9mm |
| Discrete GPU manufacturer | NVIDIA |
| Discrete graphics card | Yes |
| Discrete graphics card memory | 8GB |
| Discrete graphics card model | NVIDIA Quadro T1000 |
| Discrete graphics memory type | GDDR6 |
| Display included | No |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| Efficient cores | 8 |
| Efficient-core base frequency | 1.5GHz |
| Efficient-core Max Turbo Frequency | 4.1GHz |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000Mbit/s |
| Graphics card Mini DisplayPort ports quantity | 4 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| Height | 37mm |
| Internal memory | 32GB |
| Internal memory type | DDR5-SDRAM |
| Keyboard included | Yes |
| LAN controller | Intel® I219-LM |
| Maximum internal memory | 64GB |
| Maximum turbo power | 106W |
| Memory channels | Dual-channel |
| Memory clock speed | 4800MHz |
| Memory layout (slots x size) | 2 x 16GB |
| Memory slots | 2x SO-DIMM |
| Motherboard chipset | Intel Q670 |
| Mouse included | Yes |
| Non-ECC | Yes |
| Non-operating altitude | 0 - 12192m |
| Number of discrete graphics cards | 1 |
| Number of processors installed | 1 |
| Number of speakers | 1 |
| Number of SSDs installed | 1 |
| Number of storage drives installed | 1 |
| NVMe | Yes |
| On-board GPU manufacturer | Intel |
| On-board graphics card | Yes |
| On-board graphics card family | Intel® UHD Graphics |
| On-board graphics card model | Intel UHD Graphics 770 |
| Operating altitude | 0 - 3048m |
| Operating relative humidity (H-H) | 20 - 80% |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Operating system language | English |
| Operating temperature (T-T) | 10 - 35°C |
| Optical drive type | No |
| Password protection | Yes |
| Password protection type | BIOS, Power on, Supervisor |
| Performance cores | 8 |
| Performance-core base frequency | 2.1GHz |
| Performance-core Max Turbo Frequency | 5.1GHz |
| Placement supported | Horizontal/Vertical |
| Power supply | 300W |
| Power supply input voltage | 100 - 240V |
| Processor base power | 35W |
| Processor cache | 30MB |
| Processor cache type | Smart Cache |
| Processor cores | 16 |
| Processor family | Intel® Core™ i7 |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor manufacturer | Intel |
| Processor model | i7-13700 |
| Processor threads | 24 |
| Product colour | Black |
| Product type | Mini PC |
| SSD capacity | 2TB |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| Storage media | SSD |
| Storage relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 60°C |
| Total SSDs capacity | 2TB |
| Total storage capacity | 2TB |
| Trusted Platform Module (TPM) | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Volume | 1L |
| Weight | 1.4kg |
| Width | 179mm |
| Wi-Fi | No |
| Processor | 13th gen Intel® Core™ i7 i7-13700 |
| Memory | 32GB DDR5-SDRAM |
| Internal Storage | 2TB M.2 SSD |
