Product Description
Overview
- Proven performance and reliability to deliver maximum investment protection.
- Offering the perfect combination of performance, reliability and investment protection to any IT environment. For businesses that require superior stability and manageability with low lifecycle costs, or desktops with proven technology, superior price/performance and a wide choice of features, or even entry-level PCs that balance price and essential computing capabilities – the HP Desktop family holds the solution.
- A desktop that can travel
- The HP Elite Mini 800 Desktop PC delivers the high-performance needed to develop complex presentations, crunch big numbers, and quickly create compelling content. Equipped with a powerful Intel® processor[2], responsive graphics, and smart deployment options, this is the right PC for big jobs done in small spaces.
Features
- At least 50 percent of all plastic used in this PC is post-consumer recycled plastic.[7]
- HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense.[6]
- Take the HP Elite Mini 800 home with you so you can stay productive in the hybrid work world.
- Get breakthrough performance with the latest Intel® processor[2] and DDR5 memory.
Product Videos
Specifications
| Spec | Description |
|---|---|
| Wireless Model | Wi-Fi 6E AX211 |
| Wireless supplier | Intel® |
| Ports | 1 headset connector; 1 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed USB Type-A 10Gbps signaling rate (charging); 1 SuperSpeed USB Type-C® 20Gbps signaling rate; 1 external antenna connector; 1 power connector; 1 RJ-45; 3 SuperSpeed US... |
| Expansion slots note | 1 M.2 2230 slot for WLAN and 2 M.2 2280 slots for storage |
| Expansion slots | 1 M.2 2230; 2 M.2 2280 |
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card (supporting gigabit data rate) |
| Wireless transfer speeds | Supporting Gigabit data rate |
| Wireless standard | Wi-Fi 6E |
| I/O Port location | Rear; Front |
| vPro enabled | vPro® |
| Bluetooth version | Bluetooth® 5.2 |
| Wireless antenna | 2x2 |
| Network interface type | WLAN |
| Datasheet photo 3 | AHID/160bde11973b5083e06909f14eaeaf3af535365e |
| Datasheet photo 5 | AHID/16dce1db978263cda71d677af1704ffa97647685 |
| Datasheet photo 4 | AHID/09708d93c70aff896b1c20f4cca3b88edb9731b1 |
| Datasheet photo 1 | AHID/c0619eacb57da100b94fd68204cdb341fe988d98 |
| UNSPSC code | 43211507 |
| Form factor | Mini |
| Operating humidity range | 10 to 90% RH |
| Operating temperature range | 50 to 95°F; 10 to 35°C |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Processor cache | 24 MB L3 |
| Processor maximum frequency uom | GHz |
| Processor family | Intel® Core™ i7 14th generation processor; Core™ i7 |
| Processor model | 14700T |
| Processor core | 20 |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Processor | Intel® Core™ i7-14700T (up to 5.0 GHz Max Turbo frequency, 33 MB L3 cache, 20 cores, 28 threads) |
| Processor Brand | Intel® |
| Processor generation | 14th Generation |
| Processor maximum frequency | 5.0 |
| Processor threads | 28 |
| Chipset | Intel® Q670 (vPro®) |
| Operating system | Windows 11 Pro |
| Playbook TS icon storage | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png |
| Playbook TS icon dimensions tower | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png |
| Playbook TS icon memory | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png |
| Playbook TS icon weight imperial | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png |
| Playbook TS icon processor | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png |
| Playbook TS icon weight metric | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png |
| Playbook TS icon OS | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png |
| Playbook TS icon connectivity | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png |
| Playbook TS icon graphics | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png |
| Memory size uom | GB |
| Memory and storage | 16 GB memory; 256 GB SSD storage |
| Memory module type | SODIMM |
| Standard memory note | Transfer rates up to 5600 MT/s. |
| Memory type | DDR5 |
| Memory | 16 GB DDR5-5600 MHz RAM (2 x 8 GB) |
| Memory speed | 5600 |
| Memory speed uom | MHz |
| Number of memory slots | 2 |
| Memory size | 16 |
| Memory layout (slots & size) | 2 x 8 GB |
| Memory Slots | 2 SODIMM |
| Internal drive bays | One 2.5" HDD |
| Storage interface 01 | PCIe® |
| Storage capacity | 256 |
| Storage type | SSD |
| Storage capacity uom 01 | GB |
| Storage form factor 01 | M.2 |
| Internal Storage | 256 GB PCIe® NVMe™ M.2 SSD |
| Storage interface protocol 01 | NVMe™ |
| Storage type 01 | SSD |
| Package dimensions (W x D x H) | 49.8 x 13.2 x 23.5 cm |
| Minimum dimensions (W x D x H) | 17.7 x 17.5 x 3.4 cm |
| Package dimension note (metric) | Packaging material used will vary by Country |
| UPC number | 198415185068 |
| Security management | HP Secure Erase; HP Sure Click; HP Sure Sense; Absolute Persistence module; HP Sure Admin; HP BIOSphere Gen6; HP Client Security Manager Gen7; HP Tamper Lock; HP Sure Start Gen7; HP Sure Run Gen5; HP Sure Recover Gen5; Trusted Platform Module TPM ... |
| Power | 90 W external power adapter, up to 89% efficiency, active PFC |
| Package weight | 2.95 kg |
| Weight note (metric) | Exact weight depends on configuration. |
| Weight | 1.42 kg |
| Audio | Realtek ALC3252 codec, universal audio jack with CTIA and OMTP headset support |
| Pointing device | HP Wired 320M Mouse |
| Keyboard interface | USB |
| Keyboard | HP Wired Desktop 320K Keyboard |
| Available software | HP Smart Support |
| Management features | HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Connect for Microsoft Endpoint Manager; HP Manageability Integration Kit (download); HP Patch Assistant (do... |
| Software included | HP Notifications; HP PC Hardware Diagnostics UEFI; HP Support Assistant; HP Connection Optimizer; HP Privacy Settings; HP PC Hardware Diagnostics Windows; HP Desktop Support Utilities; MyHP; HP Easy Clean; Touchpoint Customizer for Commercial; HP ... |
| Energy star certified | ENERGY STAR® certified |
| Ecolabels | EPEAT® registered |
| Legal tagline | HP recommends Windows 11 Pro for business |
| Graphics (integrated) | Intel® UHD Graphics 770 |
| Graphics | Integrated |
| Product long name specifications | HP Elite Mini 800 G9 Desktop PC, Windows 11 Pro, Intel® Core™ i7, 16GB RAM, 256GB SSD |
| Product short name specifications | HP Elite Mini 800 G9 Desktop PC, Intel® Core™ i7, 16GB RAM, 256GB SSD |
| Facet Form factor | Mini |
| Facet Weight (lb) | 3.13 |
| Facet Product type | Desktops |
| Facet Subcategory | Desktop and All-in-One |
| Facet Sub brand | Elite |
| Facet Series name | HP Elite Mini 800 G9 |
| Facet Processor generation | 14th Generation |
| Facet Processor type | Intel Core i7 |
| Facet RAM (GB) | 16 |
| Facet Storage (GB) | 256 |
| Facet Usage | Mission critical |
| Facet Taxonomy | Desktop and All-in-One |
| Facet Segment | Business |
| Facet Features | HP Wired Desktop 320K Keyboard; HP Secure Erase; HP Sure Click; HP Sure Sense; Absolute Persistence module; HP Sure Admin; HP BIOSphere Gen6; HP Client Security Manager Gen7; HP Tamper Lock; HP Sure Start Gen7; HP Sure Run Gen5; HP Sure Recover Ge... |
| Facet Operating system | Windows 11 Pro |
| Facet Environmental certification | ENERGY STAR® certified; EPEAT® registered |
| Facet Ports | 1 headset connector; 1 SuperSpeed USB Type-A 10Gbps signaling rate; 1 SuperSpeed USB Type-A 10Gbps signaling rate (charging); 1 SuperSpeed USB Type-C® 20Gbps signaling rate, 1 external antenna connector; 1 power connector; 1 RJ-45; 3 SuperSpeed US... |
| Facet Graphics | Intel UHD |
