Product Description
Overview
- Offering the perfect combination of performance, reliability and investment protection to any IT environment. For businesses that require superior stability and manageability with low lifecycle costs, or desktops with proven technology, superior price/performance and a wide choice of features, or even entry-level PCs that balance price and essential computing capabilities – the HP Desktop family holds the solution.
- Proven performance and reliability to deliver maximum investment protection.
- The HP EliteOne 870 AiO empowers your team to be at their best with experiences that delight users and IT. Featuring a new sleek design, the latest Intel® processor[2], and packed with a new set of premium collaboration tools, it’s ready for all your demanding projects and virtual conferences.
- Be there even when you’re not
Features
- At least 50 percent of all plastic used in this PC is post-consumer recycled plastic.[7]
- HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense.[6]
- Multitask with ease thanks the latest Intel® processor2, massive storage, and agile DDR5 memory.
- Bring your meetings to life powered by premium audio and video features.[4]
Product Videos
Specifications
| Spec | Description |
|---|---|
| Wireless Model | Wi-Fi 6E AX211 |
| Ports | 1 USB Type-C® 20Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate; 1 headphone/microphone combo; 1 USB Type-C® 10Gbps signaling rate (DisplayPort™ 1.4); 2 USB Type-A 10Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 1 HDMI... |
| I/O Port location | Rear; Right side; Left side |
| Wireless transfer speeds | Supporting Gigabit data rate |
| Expansion slots note | 1 M.2 2230 slot for WLAN and Bluetooth®️ combo. 3 M.2 2280 for NVMe SSD for storage one attached to CPU PCIe Gen 4.0 and two attached to PCH PCIe Gen 3.0 |
| Expansion slots | 1 M.2 2230; 3 M.2 2280 |
| Wireless standard | Wi-Fi 6E |
| Wireless supplier | Intel® |
| Wireless antenna | 2x2 |
| vPro enabled | vPro® |
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card (supporting gigabit data rate) |
| Bluetooth version | Bluetooth® 5.3 |
| Network interface type | WLAN |
| Form factor | All-in-one |
| UNSPSC code | 43211507 |
| Display size (diagonal) uom | " |
| Display size (diagonal, metric) uom | cm |
| Color gamut | 72% NTSC |
| Display brightness uom | nits |
| Display brightness | 250 |
| Display | 68.6 cm (27") diagonal QHD touch display; 27" diagonal, QHD (2560 x 1440), touch, IPS, 250 nits, 72% NTSC; 27" diagonal QHD touch display; 68.6 cm (27") diagonal, QHD (2560 x 1440), touch, IPS, 250 nits, 72% NTSC |
| Display size (diagonal, imperial) | 27 |
| Display resolution standard | QHD |
| Display panel technology | IPS |
| Display resolution (pixels) | 2560 x 1440 |
| Display size (diagonal, metric) | 68.6 |
| Trademark information | Intel®, the Intel logo, Intel Core, vPro®, Optane™, and Core Inside are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Bluetooth® is a trademark of its proprietor, used by HP ... |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Processor maximum frequency | 5.4 |
| Chipset | Intel® Q670 (vPro®) |
| Processor generation | 14th Generation |
| Processor | Intel® Core™ i7-14700 (up to 5.4 GHz with Intel® Turbo Boost Technology, 33 MB L3 cache, 16 cores, 28 threads) |
| Processor Brand | Intel® |
| Processor family | Intel® Core™ i7 14th generation processor; Core™ i7 |
| Processor model | 14700 |
| Processor cache | 33 MB L3 cache |
| Processor maximum frequency uom | GHz |
| Processor threads | 28 |
| Processor core | 16 |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Memory | 16 GB DDR5-4800 MHz RAM (1 x 16 GB) |
| Memory Slots | 2 SODIMM |
| Memory module type | SODIMM |
| Memory speed uom | MHz |
| Memory size | 16 |
| Memory speed | 4800 |
| Memory type | DDR5 |
| Memory size uom | GB |
| Memory and storage | 16 GB memory; 512 GB SSD storage |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Number of memory slots | 1 |
| Memory layout (slots & size) | 1 x 16 GB |
| Storage capacity uom 01 | GB |
| Storage interface protocol 01 | NVMe™ |
| Storage capacity | 512 |
| Internal Storage | 512 GB PCIe® Gen4 NVMe™ TLC M.2 SSD |
| Storage interface 01 | PCIe® Gen 4 |
| Storage memory technology 01 | TLC |
| Storage form factor 01 | M.2 |
| Storage type 01 | SSD |
| Storage type | SSD |
| Package weight | 15.07 kg |
| Weight | 11.6 kg |
| Weight note (metric) | Exact weight depends on configuration. |
| Audio | Audio by Bang & Olufsen, 5 W stereo speakers, headset and headphone side ports (3.5 mm), high performance integrated stereo speakers |
| Keyboard interface | USB |
| Pointing device | HP Wired 320M Mouse |
| Keyboard | HP Wired Desktop 320K Keyboard |
| Certifications and compliances | TCO 8.0; TUV Low Blue Light; TUV Low Noise |
| Sustainable impact specifications | Ocean-bound plastic in speaker enclosure; 40% post-consumer recycled plastic; 30% ITE-derived closed loop plastic; Low Halogen; 80 Plus® Platinum power supplies available |
| Energy star certified | ENERGY STAR® certified |
| Ecolabels | TCO Certified Edge |
| Management features | HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Connect for Microsoft Endpoint Manager; HP Manageability Integration Kit (download); HP Patch Assistant (do... |
| Available software | HP Smart Support |
| Legal tagline | HP recommends Windows 11 Pro for business |
| Camera resolution | 5 |
| Camera Infrared | IR |
| Camera microphone | integrated dual array digital microphones |
| Camera resolution uom | MP |
| Camera | 5 MP Swivel IR camera for face authentication with Windows Hello with integrated dual array digital microphones and Color Light Sensor |
| Datasheet photo 5 | AHID/cb65407f5b873c46c843aa27170dd78c30a56fbf |
| Datasheet photo 4 | AHID/55d11e569d4b094c16d4169567c24a2a01d4fa6a |
| Datasheet photo 3 | AHID/0a9833d5c8e03f58163732eaf76cb304f3eb309b |
| Datasheet photo 1 | AHID/82491298884248b053e2e3562e0d3b5d9b89b15a |
| Operating temperature range | 50 to 95°F; 10 to 35°C |
| Operating humidity range | 10 to 90% RH |
| Manufacturer Warranty | 1 year (1/1/1) limited warranty includes 1 year of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Operating system | Windows 11 Pro |
| Playbook TS icon storage | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png |
| Playbook TS icon dimensions tower | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png |
| Playbook TS icon dimensions AiO | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169107.png |
| Playbook TS icon memory | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png |
| Playbook TS icon weight imperial | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png |
| Playbook TS icon processor | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png |
| Playbook TS icon display AiO | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c06122537.png |
| Playbook TS icon weight metric | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png |
| Playbook TS icon OS | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png |
| Playbook TS icon connectivity | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png |
| Playbook TS icon graphics | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png |
| Additional storage | 4-in-1 media card reader |
| Minimum dimensions (W x D x H) | 61.4 x 24.7 x 59.95 cm |
| Package dimensions (W x D x H) | 74.2 x 23.7 x 64.0 cm |
| UPC number | 198415185136 |
| Security management | Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); HP Sure Start; HP Secure Erase; HP Sure Click; HP Sure Sense; Absolute Persistence module; HP Sure Admi... |
| Graphics | Integrated |
| Graphics (integrated) | Intel® UHD Graphics |
| Product long name specifications | HP EliteOne 870 G9 All-in-One Touchscreen PC, 27", Windows 11 Pro, Intel® Core™ i7, 16GB RAM, 512GB SSD, QHD |
| Product short name specifications | HP EliteOne 870 G9 All-in-One Touchscreen PC, 27", Intel® Core™ i7, 16GB RAM, 512GB SSD |
| Facet Weight (lb) | 29.54 |
| Facet Sub brand | EliteOne |
| Facet Product type | Desktops |
| Facet Subcategory | Desktop and All-in-One |
| Facet Series name | HP EliteOne 870 27 G9 |
| Facet Processor type | Intel Core i7 |
| Facet Processor generation | 14th Generation |
| Facet RAM (GB) | 16 |
| Facet Segment | Business |
| Facet Taxonomy | Desktop and All-in-One |
| Facet Storage (GB) | 512 |
| Facet Screen size (in) | 27 |
| Facet Maximum resolution | 2540 x 1440 |
| Facet Ports | 1 headphone/microphone combo, 1 USB Type-C® 20Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate, 1 USB Type-C® 10Gbps signaling rate (DisplayPort™ 1.4); 2 USB Type-A 10Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 1 HDMI... |
| Facet Form factor | All-in-One |
| Facet Features | HP Wired Desktop 320K Keyboard; IR; Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); HP Sure Start; HP Secure Erase; HP Sure Click; HP Sure Sense; Absol... |
| Facet Environmental certification | ENERGY STAR® certified |
| Facet Operating system | Windows 11 Pro |
| Facet Graphics | Intel UHD |
