| Spec | Description |
|---|---|
| Connectivity, standard | Gigabit Ethernet (1000Base-T) |
| UNSPSC code | 43212104 |
| Datasheet photo 1 | AHID/f446b1231cc89b94b21985e9bc58a4c1f503f76d |
| Finished output handling | Roll feed, take-up reel, wiper roller[3], automatic horizontal cutter (for vinyl, banner and canvas[4], paper-based media, and film) |
| Product logos | 3M MCS Warranty; CE marking; ENERGY STAR; EPEAT green; HP water-based technology; i1 Color Technology; Roadmap to Zero; UL Ecologo; UL GREENGUARD Gold |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Operating humidity range | 20 to 80% RH (non-condensing) |
| Operating temperature range | 15 to 30ºC; 59 to 86ºF |
| Acoustic power emissions (active, printing) | 7.8 B(A) (operating), 5.5 B(A) (idle), <3.5 B(A) (sleep) |
| Acoustic pressure emissions | 60 dB(A) (operating), 38 dB(A) (idle), <20 dB(A) (sleep) |
| Manufacturer Warranty | One-year limited hardware warranty |
| Technology logo, print 8 | AHID/1e91d93736dc653f1e288830d6267e3622470fb5 |
| Technology logo, print 1 | AHID/9d4f4360d8675941eb5a8fbad7e4685c3e845ba4 |
| Technology logo, print 2 | AHID/ef8c86134678c08f512b085ef40e4c627ae15ed4 |
| Technology logo, print 3 | AHID/95142d0f2ba4b6d45a004d774f64f5f379ea070e |
| Technology logo, print 4 | AHID/7f5fb10b352c00f2fb80593f9113010f5a12d28c |
| Technology logo, print 5 | AHID/be52cf8425d358b8df062588616a5a255ba379fb |
| Technology logo, print 6 | AHID/7dd1fab03b56b0736cb73329b53d542f8c74700a |
| Technology logo, print 7 | AHID/66ba9d5f33313f6995d9ec2798d4357acc6d1cd0 |
| Color(s) of printing supplies | Black, cyan, light cyan, light magenta, magenta, yellow, white, HP Latex Optimizer, HP Latex Overcoat |
| Ink types | Water-based HP Latex Inks |
| Number of print cartridges | 9 (black, cyan, light cyan, light magenta, magenta, yellow, white, HP Latex Optimizer, HP Latex Overcoat) |
| Print heads | 10 (2 cyan/black, 2 magenta/yellow, 2 light cyan/light magenta, 2 white, 1 HP Latex Optimizer, 1 HP Latex Overcoat) |
| Print Technology | Ink |
| Print cartridge volume delivered | 3 L |
| Print speed | 122 m²/hr - Max Speed (1-pass); 36 m²/hr - High Speed (4-pass); 25 m²/hr - Production Fast (6-pass); 20 m²/hr - Production Quality, Textiles and Backlits (8-pass); 17 m²/hr - High Saturation (12-pass); 14 m²/hr - High Saturation Backlits and Texti... |
| Print quality color (best) | Up to 1200 x 1200 dpi |
| Minimum dimensions (W x D x H) | 101.7 x 34.1 x 55.2 in; 2583 x 866 x 1402 mm |
| Package dimensions (W x D x H) | 2753 x 1100 x 1666 mm; 108.4 x 43.3 x 65.6 in |
| Operating area | 110 x 82.7 in; 2793 x 2100 mm |
| UPC number | (ABG) 194441547955; (B19) 194441547924; (B1K) 194441547931; (BCD) 194441547948 |
| Power consumption | 1.8-2.8 kW (5 kW peak) (printing), 105 W (ready) |
| Power | Input voltage (auto ranging) 200-240 V (±10%) two wires and PE; 50/60 Hz (±3 Hz); two power cords; 16 A max per power cord |
| What's in the box | HP Latex 800 W Printer, printheads, maintenance cartridge, printer stand, take-up reel, user maintenance kit, edge holders, quick reference guide, documentation software, power cords, air purgers, 2-in spindle adaptor |
| Model size | 1626 mm; 64 in |
| Print repeatability | 95% of colors ≤ 1.5 dE2000[2] |
| Print repeatability note | [2] The color variation between printed jobs has been measured at 12 pass mode on vinyl media following best practices for tiling layouts and within this limit: 95th percentile of pairwise color differences (95% of colors) ≤ 1 dE2000. Reflective m... |
| Media thickness (metric) | Up to 0.5 mm |
| Media types | Banners, self-adhesive vinyls, films, fabrics, papers, wall coverings, canvas, synthetics, mesh, textiles[5] |
| Media width, maximum | 1625 mm; 64 in |
| Media thickness | Up to 19.7 mil |
| Weight | 300 kg; 661 lb |
| Package weight | 437 kg; 963.4 lb |
| Recommended media | HP PVC-free Wallpaper (UL GREENGUARD GOLD Certified[6], FSC® certified[7], meets AgBB criteria[8]); HP Photo-realistic Poster Paper; HP Premium Satin Canvas; HP Prime Matte Air GP (REACH compliant[9]); HP Premium Removable Gloss Adhesive Vinyl (RE... |
| Media sizes standard (metric rolls) | 419 to 1625-mm rolls (580 to 1625-mm rolls with full support) |
| Media sizes standard (sheets, rolls) | 16.5 to 64-in rolls (23 to 64-in rolls with full support) |
| Roll external diameter | 250 mm; 9.8 in |
| Roll maximum input | 1 |
| Roll maximum weight | 55 kg; 121 lb |
| Supported Primary Applications | Banners; Displays; Exhibition and event graphics; Exterior signage; Indoor posters; Interior decoration; Light boxes - film; Light boxes - paper; Murals; POP/POS; Posters; Textile; Vehicle graphics; Window graphics; Stickers |
| Additional information about HP in the countries | http://www.hp.com/uk |
| Additional information about HP | http://www.hp.com |
| Web address for additional information | http://www.hp.com/go/latex800series |
| Electromagnetic compatibility | Compliant with Class A requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia and New Zealand (RCM), Japan (VCCI), Korea (KCC), China (CCC) |
| Energy star certified | Yes |
| Environmental certification | ENERGY STAR®; RoHS (WEEE, EU, EAEU, China, Korea, India, Ukraine, Turkey); REACH; EPEAT Silver; OSHA; CE marking compliant; Meets AgBB criteria; French VOC A+; Greenguard Gold; UL Ecologo; ZDHC - Level 1 |
| Safety | IEC 60950-1+A1+A2 compliant; IEC 62368-1 compliant; USA and Canada (CSA listed); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia, Belarus, and Kazakhstan (EAC); China (CCC) |
| Dynamic security | Dynamic security enabled printer |
| Facet Primary applications | Advertising posters, roll-ups, and banners; Indoor signage; Outdoor signage; Textile - soft signage; Décor |
| Facet Sub brand | Latex |
| Facet Product type | Low-volume Printers |
| Facet Subcategory | Latex Printers |
