Product Description
Overview
- What if you could have 40 GbE connection using existing LC cables in your data center? The HPE 40Gb QSFP+ Bi-directional Transceiver integrates four electrical data lanes in each direction into transmission over a single LC duplex fiber optic cable. Together with other HPE 40GbE QSFP+ MPO Transceivers, it provides more flexibility and variety of high-density and low-power 40GbE solutions for Hewlett Packard Enterprise server users.
Features
- Hot pluggable transceiver for ease of installation.
- Low power consumption with a maximum power consumption of 3.5 W.
- The 40Gb QSFP+ Bi-directional Transceiver links up to 100 m using OM3 and OM4 optical fiber for flexibility.
- Compliant with the 40GbE XLPPI and QSFP+ SFF-8436 electrical specification from IEEE.
- The HPE 40Gb QSFP+ Bi-directional Transceiver provides an LC duplex connector to allow re-use of existing cable infrastructure in the data center.
Product Videos
Specifications
| Spec | Description |
|---|---|
| Product long name specifications | HPE 40Gb QSFP+ Bidirectional Transceiver |
| Connector type | LC duplex |
| Transceiver form factor | QSFP+ |
| Ports | 40GBASE-SR-BiDi |
| Wavelength | 850nm/900nm |
| Weight | 0.08 lb; 35 g |
| Minimum dimensions ( H x W x D) | 121.8 x 18.35 x 12.9 mm |
