Product Description
Overview
- Proven performance and reliability to deliver maximum investment protection.
- Offering the perfect combination of performance, reliability and investment protection to any IT environment. For businesses that require superior stability and manageability with low lifecycle costs, or desktops with proven technology, superior price/performance and a wide choice of features, or even entry-level PCs that balance price and essential computing capabilities – the HP Desktop family holds the solution.
- Empower your teams with rich, immersive collaborative experiences across town and around the world in an instant. Powered by an Intel® Processor[2], the HP Mini IP Conferencing PC with Microsoft Teams Rooms[3] is designed to work with your existing Microsoft Teams Rooms certified audiovisual infrastructure, including touch-control panels the Poly TC10 controller[6], and up to two displays.[4,5]
- Empower your teams with rich, immersive collaborative experiences across town and around the world in an instant with the HP Mini IP Conferencing PC with Microsoft Teams Rooms.[3]
- Skip the configuration and start your meeting
Features
- Get a highly secure and manageable PC that has the self-healing protection of HP Sure Start Gen7.[7]
- At least 50 percent of all plastic used in this PC is post-consumer recycled plastic.[9]
- Quickly setup your conferencing space with Microsoft Teams Rooms[3] preinstalled.[6]
- Deploy this PC into your existing Microsoft Teams Rooms[3] environment, where it can drive up to two displays.[4]
Product Videos
Specifications
| Spec | Description |
|---|---|
| Wireless supplier | Intel® |
| Wireless Model | Wi-Fi 6E AX211 |
| Wireless standard | Wi-Fi 6E |
| Wireless antenna | 2x2 |
| Bluetooth version | Bluetooth® 5.2 |
| Wireless transfer speeds | Supporting Gigabit data rate |
| vPro enabled | vPro® |
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card (supporting gigabit data rate) |
| Ports | 1 USB Type-C® 20Gbps signaling rate; 1 USB Type-A 10Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate; 1 USB Type-C® 10Gbps signaling rate (DisplayPort™); 1 USB Type-C® 10Gbps signaling rate; 3 USB Type-A 10Gbps signaling rate; 1 ... |
| I/O Port location | Front; Rear |
| Expansion slots | 1 M.2 2230; 2 M.2 2280 |
| Expansion slots note | 1 M.2 2230 slot for WLAN and 2 M.2 2280 slots for storage |
| UNSPSC code | 43211507 |
| Form factor | Mini |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Image legal disclaimer | Product image may differ from actual product |
| Processor family | Core™ i7; 13th Generation Intel® Core™ i7 processor |
| Processor maximum frequency | 4.9 |
| Processor model | 13700T |
| Processor Brand | Intel® |
| Processor threads | 24 |
| Processor generation | 13th Generation |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Processor maximum frequency uom | GHz |
| Processor core | 16 |
| Processor | Intel® Core™ i7-13700T (up to 4.9 GHz with Intel® Turbo Boost Technology, 30 MB L3 cache, 16 cores, 24 threads) |
| Processor type | Intel Core i7 |
| Chipset | Intel® Q670 (vPro®) |
| Processor cache | 30 MB L3 |
| Segment | Business |
| Product type | Desktops |
| Subcategory | Desktop and All-in-One |
| Series name | HP Mini Conferencing |
| Sub brand | Collaboration Solutions |
| Memory speed | 4800 |
| Number of memory slots | 2 |
| Memory size | 16 |
| Memory type | DDR5 |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory size uom | GB |
| Memory speed uom | MT/s |
| Memory module type | SODIMM |
| Memory | 16 GB DDR5-4800 MT/s (2 x 8 GB) |
| Memory layout (slots & size) | 2 x 8 GB |
| Memory and storage | 16 GB memory; 256 GB SSD storage |
| RAM (GB) | 16 |
| Memory Slots | 2 SODIMM |
| Usage | Premium computing |
| Taxonomy | Desktop and All-in-One |
| Storage (GB) | 256 |
| Power | 150 W external power adapter, up to 89% efficiency |
| Weight note (metric) | Exact weight depends on configuration. |
| Package weight | 2.95 kg |
| Weight | 1.42 kg |
| Audio | Realtek ALC3252 codec, universal audio jack with CTIA and OMTP headset support |
| Features | HP Sure Start Gen7; Wi-Fi 6E; 1 USB Type-C® 20Gbps signaling rate; 1 USB Type-A 10Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate; 1 USB Type-C® 10Gbps signaling rate (DisplayPort™); 1 USB Type-C® 10Gbps signaling rate; 3 USB Ty... |
| Manageability Features 1 | HP Image Assistant (download) |
| Manageability Features 2 | HP Manageability Integration Kit (download) |
| Software included | Microsoft Teams Rooms |
| Management features | HP Console Control; Poly Lens |
| Datasheet photo 1 | AHID/53e97e9ef99dd269c250139d80f82f7b14816161 |
| Operating humidity range | 10 to 90% RH |
| Total CO2e (kg) | 190 |
| Transportation CO2e (kg) | 0.5 |
| Energy Usage CO2e (kg) | 86 |
| Production CO2e (kg) | 101 |
| End of Life CO2e (kg) | 0.8 |
| Total CO2e (kg) note | A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in ... |
| Operating temperature range | 10 to 35°C; 50 to 95°F |
| Operating system | Windows 11 IoT Enterprise |
| Playbook TS icon weight imperial | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png |
| Playbook TS icon storage | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png |
| Playbook TS icon dimensions tower | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png |
| Playbook TS icon processor | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png |
| Playbook TS icon memory | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png |
| Playbook TS icon graphics | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png |
| Playbook TS icon connectivity | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png |
| Playbook TS icon OS | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png |
| Playbook TS icon weight metric | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png |
| Package dimension note (metric) | Packaging material used will vary by Country |
| Dimensions (W x D x H) | 17.7 x 17.5 x 3.4 cm |
| Package dimensions (W x D x H) | 49.2 x 11.4 x 25.1 cm |
| UPC number | 198122884216 |
| Security management | HP Sure Start Gen7; HP Sure Sense; HP Sure Start |
| Storage form factor 01 | M.2 |
| Storage capacity | 256 |
| Storage interface 01 | PCIe® |
| Storage interface protocol 01 | NVMe™ |
| Storage type 01 | SSD |
| Storage capacity uom 01 | GB |
| Internal Storage | 256 GB PCIe® NVMe™ M.2 SSD |
| Graphics | Integrated |
| Graphics (integrated) | Intel® UHD Graphics 770 |
| Product short name specifications | HP Mini IP Conference PC with Microsoft Team Rooms, Intel® Core™ i7, 16GB RAM, 256GB SSD |
| Product long name specifications | HP Mini IP Conference PC with Microsoft Team Rooms, Windows 11 IoT Enterprise, Intel® Core™ i7, 16GB RAM, 256GB SSD |
| Facet Segment | Business |
| Facet Product type | Desktops |
| Facet Subcategory | Desktop and All-in-One |
| Facet Series name | HP Mini Conferencing |
| Facet Sub brand | Collaboration Solutions |
| Facet Processor generation | 13th Generation |
| Facet Processor type | Intel Core i7 |
| Facet RAM (GB) | 16 |
| Facet Usage | Premium computing |
| Facet Taxonomy | Desktop and All-in-One |
| Facet Storage (GB) | 256 |
| Facet Features | HP Sure Start Gen7; Wi-Fi 6E; 1 USB Type-C® 20Gbps signaling rate; 1 USB Type-A 10Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate; 1 USB Type-C® 10Gbps signaling rate (DisplayPort™); 1 USB Type-C® 10Gbps signaling rate; 3 USB Ty... |
| Facet Operating system | Windows 11 IoT Enterprise |
| Facet Ports | 1 USB Type-C® 20Gbps signaling rate; 1 USB Type-A 10Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate, 1 USB Type-C® 10Gbps signaling rate (DisplayPort™); 1 USB Type-C® 10Gbps signaling rate; 3 USB Type-A 10Gbps signaling rate; 1 ... |
