Product Description
Overview
- Offering the perfect combination of performance, reliability and investment protection to any IT environment. For businesses that require superior stability and manageability with low lifecycle costs, or desktops with proven technology, superior price/performance and a wide choice of features, or even entry-level PCs that balance price and essential computing capabilities – the HP Desktop family holds the solution.
- Proven performance and reliability to deliver maximum investment protection.
- The HP EliteOne 840 AiO empowers your team to be at their best with experiences that delight users and IT. Featuring a new sleek design, the latest Intel® processor[2], and packed with a new set of premium collaboration tools, it’s ready for all your demanding projects and virtual conferences.
- Be there even when you’re not
Features
- At least 50 percent of all plastic used in this PC is post-consumer recycled plastic.[7]
- Multitask with ease thanks the latest Intel® processor[2], massive storage, and agile DDR5 memory.
- Bring your meetings to life powered by premium audio and video features.[4]
- HP Wolf Security for Business creates a hardware-enforced, always-on, resilient defense.[6]
Product Videos
Specifications
| Spec | Description |
|---|---|
| Wireless Model | Wi-Fi 6E AX211 |
| vPro enabled | vPro® |
| Expansion slots note | 1 M.2 2230 slot for WLAN and Bluetooth®️ combo. 3 M.2 2280 for NVMe SSD for storage one attached to CPU PCIe Gen 4.0 and two attached to PCH PCIe Gen 3.0 |
| Expansion slots | 1 M.2 2230; 3 M.2 2280 |
| Network interface type | WLAN |
| Ports | 1 headphone/microphone combo; 1 USB Type-C® 10Gbps signaling rate (DisplayPort™ 1.4); 2 USB Type-A 10Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 1 HDMI-in 1.4; 1 dual-mode DisplayPort™ 1.4; 1 RJ-45; 1 USB Type-C® 20Gbps signaling rate ... |
| Wireless standard | Wi-Fi 6E |
| Wireless supplier | Intel® |
| I/O Port location | Rear; Right side; Left side |
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card (supporting gigabit data rate) |
| Wireless transfer speeds | Supporting Gigabit data rate |
| Bluetooth version | Bluetooth® 5.3 |
| Wireless antenna | 2x2 |
| UNSPSC code | 43211507 |
| Form factor | All-in-one |
| Display | 60.5 cm (23.8") diagonal, FHD (1920 x 1080), touch, IPS, anti-glare, Low Blue Light, 250 nits, 72% NTSC; 23.8" diagonal FHD display; 23.8" diagonal, FHD (1920 x 1080), touch, IPS, anti-glare, Low Blue Light, 250 nits, 72% NTSC; 60.5 cm (23.8") dia... |
| Display panel technology | IPS |
| Display brightness | 250 |
| Display size (diagonal, imperial) | 23.8 |
| Display brightness uom | nits |
| Display resolution standard | FHD |
| Display resolution (pixels) | 1920 x 1080 |
| Display size (diagonal, metric) uom | cm |
| Display size (diagonal, metric) | 60.5 |
| Display size (diagonal) uom | " |
| Color gamut | 72% NTSC |
| Trademark information | Intel®, the Intel logo, Intel Core, vPro®, Optane™, and Core Inside are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Bluetooth® is a trademark of its proprietor, used by HP ... |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Processor generation | 14th Generation |
| Processor family | Core™ i5; Intel® Core™ i5 14th generation processor |
| Processor | Intel® Core™ i5-14500 (up to 5.0 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 14 cores, 20 threads) |
| Processor core | 14 |
| Processor Brand | Intel® |
| Chipset | Intel® Q670 (vPro®) |
| Processor model | 14500 |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Processor threads | 20 |
| Processor maximum frequency uom | GHz |
| Processor maximum frequency | 5.0 |
| Processor cache | 24 MB L3 |
| Number of memory slots | 2 |
| Memory speed uom | MHz |
| Memory module type | SODIMM |
| Memory speed | 4800 |
| Memory and storage | 16 GB memory; 512 GB SSD storage |
| Memory | 16 GB DDR5-4800 MHz RAM (2 x 8 GB) |
| Memory type | DDR5 |
| Memory Slots | 2 SODIMM |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory size | 16 |
| Memory layout (slots & size) | 2 x 8 GB |
| Memory size uom | GB |
| Storage form factor 01 | M.2 |
| Storage capacity uom 01 | GB |
| Internal Storage | 512 GB PCIe® NVMe™ M.2 SSD |
| Storage interface protocol 01 | NVMe™ |
| Storage interface 01 | PCIe® |
| Storage type | SSD |
| Storage capacity | 512 |
| Storage type 01 | SSD |
| Weight | 9.26 kg |
| Package weight | 12.5 kg |
| Weight note (metric) | Exact weight depends on configuration. |
| Audio | Audio by Bang & Olufsen, 5 W stereo speakers, headset and headphone side ports (3.5 mm), high performance integrated stereo speakers |
| Keyboard | HP Wired Desktop 320K Keyboard |
| Keyboard interface | USB |
| Keyboard connectivity | Wired |
| Pointing device | HP Wired 320M Mouse |
| Ecolabels | TCO Certified Edge |
| Certifications and compliances | TCO 8.0; TUV Low Blue Light; TUV Low Noise |
| Sustainable impact specifications | Ocean-bound plastic in speaker enclosure; 40% post-consumer recycled plastic; 30% ITE-derived closed loop plastic; Low Halogen; 80 Plus® Platinum power supplies available |
| Energy star certified | ENERGY STAR® certified |
| Available software | HP Smart Support |
| Management features | HP Client Catalog (download); HP Driver Packs (download); HP Image Assistant (download); HP Client Management Script Library (download); HP Connect for Microsoft Endpoint Manager; HP Manageability Integration Kit (download); HP Patch Assistant (do... |
| Legal tagline | HP recommends Windows 11 Pro for business |
| Camera | 5 MP Swivel IR camera for face authentication with Windows Hello with integrated dual array digital microphones and Color Light Sensor |
| Camera microphone | integrated dual array digital microphones |
| Camera Infrared | IR |
| Camera resolution | 5 |
| Camera resolution uom | MP |
| Datasheet photo 5 | AHID/8efc9e8ce1229e5c5856bd0ba81e7c110f6a89a9 |
| Datasheet photo 4 | AHID/588fc8cbb33f76d522174eb9eb60e0fc4f9b1245 |
| Datasheet photo 3 | AHID/79b1df66483745b98a74e51596053ffcb6714cba |
| Datasheet photo 1 | AHID/1631fae2cb34d1ac542f5a18cf4e3f46164c7492 |
| Operating temperature range | 50 to 95°F; 10 to 35°C |
| Operating humidity range | 10 to 90% RH |
| Manufacturer Warranty | 1 year (1/1/1) limited warranty includes 1 year of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Playbook TS icon dimensions tower | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png |
| Playbook TS icon memory | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png |
| Playbook TS icon dimensions AiO | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169107.png |
| Playbook TS icon weight imperial | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png |
| Playbook TS icon processor | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png |
| Playbook TS icon weight metric | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png |
| Playbook TS icon display AiO | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c06122537.png |
| Playbook TS icon OS | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png |
| Playbook TS icon connectivity | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png |
| Playbook TS icon graphics | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png |
| Playbook TS icon storage | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png |
| Operating system | Windows 11 Pro |
| Additional storage | 4-in-1 media card reader |
| Dimensions (W x D x H) Note | System dimensions may fluctuate due to configuration and manufacturing variances. |
| Minimum dimensions (W x D x H) | 53.96 x 23.8 x 55.81 cm |
| Package dimensions (W x D x H) | 62.8 x 18.6 x 67.5 cm |
| UPC number | 198415191557 |
| Security management | Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); HP Sure Start; HP Secure Erase; HP Sure Click; HP Sure Sense; Absolute Persistence module; HP Sure Admi... |
| Graphics | Integrated |
| Graphics (integrated) | Intel® UHD Graphics 770 |
| Product short name specifications | HP EliteOne 840 G9 All-in-One Touchscreen PC, 23.8", Intel® Core™ i5, 16GB RAM, 512GB SSD |
| Product long name specifications | HP EliteOne 840 G9 All-in-One Touchscreen PC, 23.8", Windows 11 Pro, Intel® Core™ i5, 16GB RAM, 512GB SSD, FHD |
| Facet Weight (lb) | 19.75 |
| Facet Product type | Desktops |
| Facet Subcategory | Desktop and All-in-One |
| Facet Series name | HP EliteOne 840 23.8 G9 |
| Facet Sub brand | EliteOne |
| Facet Processor generation | 14th Generation |
| Facet Processor type | Intel Core i5 |
| Facet RAM (GB) | 16 |
| Facet Segment | Business |
| Facet Taxonomy | Desktop and All-in-One |
| Facet Storage (GB) | 512 |
| Facet Screen size (in) | 23.8 |
| Facet Maximum resolution | 1920 x 1080 |
| Facet Ports | 1 headphone/microphone combo, 1 USB Type-C® 20Gbps signaling rate (charging); 1 USB Type-A 10Gbps signaling rate, 1 USB Type-C® 10Gbps signaling rate (DisplayPort™ 1.4); 2 USB Type-A 10Gbps signaling rate; 2 USB Type-A 5Gbps signaling rate; 1 HDMI... |
| Facet Form factor | All-in-One |
| Facet Features | HP Wired Desktop 320K Keyboard; IR; Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); HP Sure Start; HP Secure Erase; HP Sure Click; HP Sure Sense; Absol... |
| Facet Environmental certification | ENERGY STAR® certified |
| Facet Operating system | Windows 11 Pro |
| Facet Graphics | Intel UHD |
