Product Description
Features:Single input power source
Toolless Mounting Capabilities
Vertical Mounting Capabilities
Product Videos
Specifications
| Spec | Description |
|---|---|
| PDU types | Basic |
| Rack capacity | 0U |
| Mounting | Vertical |
| Product colour | Black |
| AC outlets quantity | 24 |
| Power plug | C13 coupler |
| AC outlet types | C13 coupler, C19 coupler |
| I/O ports | (20) IEC 320 C13 (4) IEC 320 C19 IEC 309 32A |
| Input connection type | IEC 309 32A |
| Output connections | (20) IEC 320 C13 (4) IEC 320 C19 |
| Cable length | 3050 |
| Nominal input voltage | 230 |
| Nominal output voltage | 230 |
| Output voltage | 230 |
| Load capacity | 7680 |
| Maximum input current per phase | 32 |
| Maximum total current draw per phase | 32 |
| Maximum power | 7680 |
| Package dimensions (WxDxH) | 152 x 127 x 2134 |
| Package weight | 6480 |
| Operating temperature (T-T) | -25 - 65 |
| Storage temperature (T-T) | 0 - 45 |
| Operating relative humidity (H-H) | 0 - 95 |
| Storage relative humidity (H-H) | 0 - 95 |
