Product Description
Overview
- Engineered for demanding graphics and processor intensive applications.
- Bringing powerful, intelligently engineered workstations to power users who demand IT that performs – with uncompromising graphics and speed. HP Workstations are easy-to-buy, quick-to-deploy and simple-to-maintain solutions that support businesses, grow with complex needs and anticipate challenges.
- Full size Z tower power at half the size
- Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow—from 3D design to real time ray tracing—now and in the future.
- Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflows while defying space constraints.
Features
- Design, simulate and—for the first time—real time ray trace on a Z2 SFF. Now fitting full height, full length professional graphics and Intel® processors, this PC delivers tower-sized performance that defies space constraints.
- Accelerate your current workflow with a multitude of options across processor, graphics, memory, storage, and I/O ports with plenty of room to upgrade and expand.
- Design, simulate and real time ray trace on a Z SFF -- FHFL pro graphics and Intel® Core™ processors.
- Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.[3]
- Accelerate your current workflow with options across processor, graphics, memory, storage, and I/O ports.
- Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.[3]
Product Videos
Specifications
| Spec | Description |
|---|---|
| Expansion slots | 1 half-height PCle 4 x16; 1 half-height PCle 3 x4; 1 half-height PCle 3 x4 (x16 connector); 1 half-height PCle 3 x1; 1 full-height PCle 4 x16; 1 full-height PCle 4 x16 (x16 connector) |
| Expansion slots note | 1 M.2 2230 slot for WLAN and 3 M.2 2280 slots for storage |
| I/O Port location | Rear; Front |
| Ports | 1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge); 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack; 3 USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; ... |
| Wireless supplier | Intel® |
| Wireless Model | Wi-Fi 6E AX211 |
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card (supporting gigabit data rate) |
| Wireless standard | Wi-Fi 6E |
| Wireless antenna | 2x2 |
| Bluetooth version | Bluetooth® 5.3 |
| Wireless transfer speeds | Supporting Gigabit data rate |
| UNSPSC code | 43211515 |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Trademark information | Intel, Pentium, the Intel logo, Intel Core, Thunderbolt, vPro, Optane, and Core Inside are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Bluetooth is a trademark of its propr... |
| Image legal disclaimer | Product image may differ from actual product |
| Compatible displays note | Supports 8 displays, driving 8 displays requires the use of integrated and discrete graphics ports. Each source can drive a total of 4 displays. At least one of the integrated graphics ports need to drive two displays in a daisy chain configuration. |
| Compatible displays | All HP Z Displays and HP DreamColor Displays are supported. For more information see www.hp.com/go/zdisplays |
| Processor cache | 33 MB L3 cache |
| Processor core | 16 |
| Processor | Intel® Core™ i7-14700 (up to 5.4 GHz with Intel® Turbo Boost Technology, 33 MB L3 cache, 20 cores, 28 threads) |
| Processor generation | 14th Generation |
| Processor model | 14700 |
| Processor family | Intel® Core™ i7 14th generation processor; Core™ i7 |
| Processor maximum frequency uom | GHz |
| Processor Brand | Intel® |
| Processor type | Intel Core i7 |
| Chipset | Intel® W680 |
| Artificial intelligence | AI Workstation |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Processor threads | 28 |
| Processor maximum frequency | 5.4 |
| Series name | HP Z2 Small Form Factor G9 Workstation |
| Product type | Workstations |
| Sub brand | Z |
| Segment | Business |
| Subcategory | Workstations |
| Memory layout (slots & size) | 1 x 16 GB |
| Memory and storage | 16 GB memory; 512 GB SSD storage |
| Memory size | 16 |
| Memory size uom | GB |
| Memory type | DDR5 |
| Memory | 16 GB DDR5-4800 MT/s (1 x 16 GB) |
| Memory speed | 4800 |
| Memory speed uom | MT/s |
| RAM (GB) | 16 |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory module type | UDIMM |
| Number of memory slots | 1 |
| ECC memory | non-ECC |
| Storage (GB) | 512 |
| Taxonomy | Workstations |
| Usage | Performance computing |
| Power | 450 W 90% efficient, wide-ranging, active PFC |
| Weight note (metric) | Exact weights depend upon configuration (System weight only) |
| Package weight | Starting at 5.9 kg; Starting at 13.1 lb |
| Weight | Starting at 5.0 kg |
| Pointing device | HP 125 Wired Mouse |
| Keyboard | HP 125 Wired Keyboard |
| Keyboard connectivity | Wired |
| Audio | Realtek ALC3252 |
| Software included | HP UWP Pack; Touchpoint Customizer for Commercial; WPS Office; HP Documentation |
| Management features | HP Client Catalog (download); HP Cloud Recovery; HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager (download); HP BIOS Configuration Utility (download); HP Image As... |
| Ecolabels | EPEAT® registered |
| Energy star certified | ENERGY STAR® certified |
| Environmental certification | EPEAT® registered |
| Features | HP 125 Wired Keyboard; HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5; Wi-... |
| Datasheet photo 1 | AHID/7aa7ade34235f7fd08e05a91ebf9fcdefe527f12 |
| Datasheet photo 4 | AHID/d9df44f9ddb47c3e50c83c925670476a32f8ba67 |
| Datasheet photo 5 | AHID/5fe80329d92dba57bbb0f1dba20b48f688e96bb8 |
| Datasheet photo 2 | Publication logos/HP_Care_Pack_RGB_blue_icon.jpg |
| Datasheet photo 3 | AHID/09392789547011a6d41d080e3b2e12bf84b0bb53 |
| Sustainable impact specifications | 80 Plus® Gold power supplies available; 25% ITE-derived closed loop plastic; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; 45% post-consumer recycled plastic; 10% ITE-derived closed loop... |
| Manufacturer Warranty | 3 year (3/3/3) limited warranty includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Playbook TS icon battery life | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905264.png |
| Playbook TS icon dimensions tower | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png |
| Playbook TS icon storage | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png |
| Playbook TS icon weight metric | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png |
| Playbook TS icon graphics | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png |
| Playbook TS icon weight imperial | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png |
| Playbook TS icon processor | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png |
| Playbook TS icon connectivity | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png |
| Playbook TS icon OS | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png |
| Playbook TS icon memory | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png |
| Operating system | Windows 11 Pro |
| Dimensions (W x D x H) Note | Standard desktop orientation. |
| Package dimensions (W x D x H) | 10 x 38.4 x 30.8 cm; 3.95 x 15.1 x 12.1 in |
| Dimensions (W x D x H) | 38.4 x 30.8 x 10 cm |
| UPC number | 198701611011 |
| Security management | HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5 |
| Form factor | Small form factor |
| External drive bays | One 3.5" HDD; One slim ODD |
| Internal Storage | 512 GB PCIe® Gen4 NVMe™ M.2 SSD |
| Storage controller | Integrated SATA (4 ports 6 Gb/s) with integrated RAID 0, 1, for PCIe SSDs supported. Requires identical hard drives (speeds, capacity, interface). |
| Storage type | SSD |
| Storage interface 01 | PCIe® Gen 4 |
| Internal drive bays | One 2.5" HDD; One 3.5" HDD; Three M.2 NVME 2280 SSD |
| Storage form factor 01 | M.2 |
| Storage type 01 | SSD |
| Storage capacity | 512 |
| Storage capacity uom 01 | GB |
| Graphics (discrete) | NVIDIA® T400 (4 GB GDDR6 dedicated) |
| Graphics | Discrete; NVIDIA® T400 |
| Graphics card brand | NVIDIA® |
| Model Number | T400 |
| Graphics card memory type | GDDR6 |
| Graphics card memory size | 4 |
| Graphics card memory size uom | GB |
| Product long name specifications | HP Z2 Small Form Factor G9 Workstation, Windows 11 Pro, Intel® Core™ i7, 16GB RAM, 512GB SSD, T400 |
| Product short name specifications | HP Z2 Small Form Factor G9 Workstation, Intel® Core™ i7, 16GB RAM, 512GB SSD |
| Facet Series name | HP Z2 Small Form Factor G9 Workstation |
| Facet Product type | Workstations |
| Facet Sub brand | Z |
| Facet Segment | Business |
| Facet Subcategory | Workstations |
| Facet Processor generation | 14th Generation |
| Facet Processor type | Intel Core i7 |
| Facet Artificial intelligence | AI Workstation |
| Facet RAM (GB) | 16 |
| Facet Storage (GB) | 512 |
| Facet Taxonomy | Workstations |
| Facet Usage | Performance computing |
| Facet Features | HP 125 Wired Keyboard; HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5; Wi-... |
| Facet Environmental certification | EPEAT® registered |
| Facet Operating system | Windows 11 Pro |
| Facet Ports | 1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge); 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack, 3 USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; ... |
| Facet Graphics | NVIDIA® T400 |
| Facet Form factor | Small form factor |
