Product Description
Dell's most powerful 16" workstation
Our ultra scalable 16" mobile workstation is optimized to your configurations.
Features
- Business Mobile workstation Clamshell Grey
- Intel® Core™ i9 i9-13950HX
- 40.6 cm (16") Full HD+ 1920 x 1200 pixels LED backlight 16:10
- 64 GB DDR5-SDRAM
- 1 TB SSD
- NVIDIA RTX 3500 Ada 12 GB Intel® UHD Graphics
- Wi-Fi 6E (802.11ax) Ethernet LAN 10,100,1000 Mbit/s Bluetooth
- Lithium-Ion (Li-Ion)
- Windows 11 Pro 64-bit
Product Videos
Specifications
| Spec | Description |
|---|---|
| AC adapter frequency | 50 - 60Hz |
| AC adapter input voltage | 100 - 240V |
| AC adapter output voltage | 19.5V |
| Accelerometer | Yes |
| Ambient light sensor | Yes |
| Antenna type | 2x2 |
| Anti-glare screen | Yes |
| Audio chip | Realtek ALC3281 |
| Battery recharge time | 3h |
| Battery technology | Lithium-Ion (Li-Ion) |
| Bluetooth | Yes |
| Built-in microphone | Yes |
| Bus type | DMI4 |
| Cable lock slot | Yes |
| Cable lock slot type | Wedge |
| Cables included | AC |
| Card reader integrated | Yes |
| Charging port type | DC-in jack |
| Combo headphone/mic port | Yes |
| Compatible memory cards | SD, SDHC, SDXC |
| Configurable TDP-down | 45W |
| CPU configuration (max) | 1 |
| Depth | 258.3mm |
| Discrete graphics card | Yes |
| Discrete graphics card memory | 12GB |
| Discrete graphics card model | NVIDIA RTX 3500 Ada |
| Discrete graphics memory type | GDDR6 |
| Display diagonal | 16" |
| Display resolution | 1920 x 1200pixels |
| Efficient-core boost frequency | 4GHz |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 10,100,1000Mbit/s |
| Fast charging | Yes |
| Form factor | Clamshell |
| Front camera | Yes |
| Front camera HD type | Full HD |
| Front camera resolution | 1920 x 1080pixels |
| Front camera resolution (numeric) | 0.92MP |
| Hall sensor | Yes |
| HD type | Full HD+ |
| HDMI ports quantity | 1 |
| Height (front) | 2.23cm |
| Height (rear) | 2.32cm |
| Infrared (IR) camera | Yes |
| Intel® Thunderbolt 4 | Yes |
| Internal memory | 64GB |
| Internal memory type | DDR5-SDRAM |
| Introduction year | 2023 |
| Keyboard backlit | Yes |
| LED backlight | Yes |
| Market positioning | Business |
| Maximum refresh rate | 60Hz |
| Memory channels | Dual-channel |
| Mobile network connection | No |
| Native aspect ratio | 16:10 |
| Non-operating altitude | -15.2 - 10668m |
| Non-operating shock | 160G |
| Non-operating vibration | 1.3G |
| Number of battery cells | 6 |
| Number of built-in speakers | 2 |
| Number of microphones | 2 |
| Number of SSDs installed | 1 |
| Numeric keypad | Yes |
| NVMe | Yes |
| On-board GPU manufacturer | Intel |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® UHD Graphics |
| Operating altitude | -15.2 - 3048m |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating shock | 110G |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Pro |
| Operating temperature (T-T) | 0 - 35°C |
| Operating vibration | 0.66G |
| Optical drive type | No |
| Password protection | Yes |
| Pixel density | 142ppi |
| Pointing device | Touchpad |
| Power adapter barrel connector | 7.4mm |
| Processor boost frequency | 5.5GHz |
| Processor cache | 36MB |
| Processor cache type | Smart Cache |
| Processor cores | 24 |
| Processor family | Intel® Core™ i9 |
| Processor generation | 13th gen Intel® Core™ i9 |
| Processor manufacturer | Intel |
| Processor model | i9-13950HX |
| Product colour | Grey |
| Product type | Mobile workstation |
| Speaker power | 2W |
| SSD capacity | 1TB |
| SSD form factor | M.2 |
| SSD interface | PCI Express 4.0 |
| Storage media | SSD |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -40 - 65°C |
| Thunderbolt 4 ports quantity | 2 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Total SSDs capacity | 1TB |
| Total storage capacity | 1TB |
| Touchscreen | No |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Video capturing speed | 30fps |
| Weight | 2.6kg |
| Width | 356mm |
| Wi-Fi data rate (max) | 2400Mbit/s |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax) |
| WLAN controller manufacturer | Intel |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Facet RAM (GB) | 64 |
| Facet Storage (GB) | 1000 |
| Facet Operating System | Windows 11 Pro |
| Facet Screen size (in) | 16 |
| Display size (diagonal) | 40.6 cm (16") |
| Processor | 13th gen Intel® Core™ i9 i9-13950HX |
| Memory | 64GB DDR5-SDRAM |
| Internal Storage | 1TB M.2 SSD |
