Product Description
Overview
- Combines the best of PC-based and proprietary POS systems
- Power to drive your business - even in small spaces
- Drive business operations with a compact high-performance platform that also offers outstanding flexibility. Suitable for a wide range of deployments that span POS, digital signage, video surveillance, processing/controlling, OEM and more.
- Drive business operations with a compact, high-performance platform with security that provides multiple deployment and configuration options.
Features
- Get high level, long-term performance from quality components like Intel® 13th Generation processors[2], up to 128GB DDR5 RAM[3], and multiple OS and port options. Plan ahead with a five-year lifecycle that lets you roll out on your schedule and extend protection with optional 5 years parts/service support.[1]
- Spend more time focusing on your business, not on technology. Enjoy automatic firmware intrusion detection and repair from day one with HP Sure Start Gen 7[4] and reduce the cost and complexity of managing your platform remotely with the HP Manageability Integration Kit.[5]
- With multiple connectivity, graphics, and networking options, plus the ability to accommodate a range of peripherals, this powerful platform can be configured for almost any environment and use case. You can also declutter & optimize tight spaces since this machine and a display can be powered with just one cord and power outlet.
- With multiple connectivity, graphics, and networking options available, this platform can be configured for almost any environment and use case.
- Get high level performance over the long term from quality components, a 5-year lifecycle, and optional 5 years parts and service support.[1]
- Focus more on your business and less on technology with automatic firmware intrusion detection and repair along with remote platform management included as standard.
Product Videos
Specifications
| Spec | Description |
|---|---|
| Ports | 1 USB Type-A 5Gbps signaling rate (charging); 2 USB Type-A 5Gbps signaling rate (charging); 2 USB 2.0 Type-A; 1 DisplayPort™ 1.4; 1 RJ-45; 1 headset connector; 2 configurable video ports; 2 USB Type-A 5Gbps signaling rate; 1 VGA |
| Ports note | Additional optional ports include up to 6 RS-232 (5/12V), up to 6 12V USB, 1 24V USB, 1 RJ-12 cash drawer. |
| Expansion slots | 2 full-height PCIe (x1); 1 half-height PCIe x16 (x4); 1 half-height PCIe x16 (x16) |
| I/O Port location | Rear; Front |
| Form factor | Small form factor |
| Country of origin | China(ABG) |
| UNSPSC code | 43211505 |
| End of Life CO2e (kg) | 2 |
| Total CO2e (kg) | 330 |
| Energy Usage CO2e (kg) | 176 |
| Transportation CO2e (kg) | 1 |
| Production CO2e (kg) | 147 |
| Operating humidity range | 20 to 85% RH |
| Operating temperature range | 10 to 40°C; 50 to 104°F |
| Sustainable impact specifications | Low Halogen |
| Total CO2e (kg) note | A product carbon footprint is defined as the total amount of greenhouse gases emitted directly and indirectly by a product over its lifetime. Greenhouse gas emissions are reported as global warming potential for 100-year time horizon (GWP-100) in ... |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Image legal disclaimer | Product image may differ from actual product |
| Support service included | HP 3 year Onsite Care Workstation Hardware Support. For terms and conditions, please visit https://h20195.www2.hp.com/v2/GetPDF.aspx/4AA8-2300EEAP & https://www8.hp.com/h20195/v2/getpdf.aspx/4AA5-7123EEAU.pdf |
| Manufacturer Warranty | 1 year (1/1/1) limited warranty includes 1 year of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Processor model | 13500TE |
| Processor Brand | Intel® |
| Processor generation | 13th Generation |
| Processor family | 13th Generation Intel® Core™ i5 processor; Core™ i5 |
| Processor maximum frequency | 4.5 |
| Processor maximum frequency uom | GHz |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Processor threads | 20 |
| Chipset | Intel® Q670 |
| Processor cache | 24 MB L3 |
| Processor core | 14 |
| Processor | Intel® Core™ i5-13500TE (up to 4.5 GHz Max Turbo frequency, 24 MB L3 cache, 14 cores, 20 threads) |
| Operating system | Windows 11 Pro |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory speed uom | MT/s |
| Memory module type | DIMM |
| Number of memory slots | 1 |
| ECC memory | non-ECC |
| Memory | 16 GB DDR5-4800 MT/s (1 x 16 GB) |
| Memory size | 16 |
| Memory size uom | GB |
| Memory type | DDR5 |
| Memory speed | 4800 |
| Memory layout (slots & size) | 1 x 16 GB |
| Memory Slots | 4 DIMM |
| Dimensions (W x D x H) | 30 x 30.2 x 10 cm |
| UPC number | 198828361271 |
| Security management | Trusted Platform Module TPM 2.0 Embedded Security Chip; USB enable/disable (via BIOS); Serial enable/disable (via BIOS); HP BIOSphere; RAID configurations; Support for chassis padlocks and cable lock devices; Solenoid lock and hood sensor; Paralle... |
| Power | 250 W internal power adapter, up to 90% efficiency, active PFC |
| Storage type | SSD |
| Internal drive bays | Two 2.5"; Two M.2 |
| Storage type 01 | SSD |
| Storage capacity | 512 |
| Storage capacity uom 01 | GB |
| Storage interface 01 | PCIe® |
| Storage interface protocol 01 | NVMe™ |
| Internal Storage | 512 GB PCIe® NVMe™ M.2 SSD |
| Weight note (metric) | Exact weight depends on configuration. |
| Weight | Starting at 3.99 kg |
| Audio | Realtek ALC3252 codec, universal audio jack, headset and headphone front ports (3.5 mm), multi-streaming capable |
| Keyboard | HP Wired Desktop 320K Keyboard |
| Pointing device | HP Wired Desktop 320M Mouse |
| Keyboard interface | USB |
| Management features | HP Driver Packs (download); HP Image Assistant; HP Manageability Integration Kit Gen4 (download) |
| Software included | HP PC Hardware Diagnostics UEFI; HP Privacy Settings; HP PC Hardware Diagnostics Windows; MyHP; HP QuickDrop; HP Easy Clean; Touchpoint Customizer for Commercial; HP Easy Clean Keyboard Driver; HSA Fusion for Commercial; HSA Telemetry for Commercial |
| Certifications and compliances | IEC 60601-1-2 |
| Graphics | Integrated |
| Graphics (integrated) | Intel® UHD Graphics 730 |
| Datasheet photo 1 | AHID/1015a70713cd2f9e5cf29b12ca4a80d9349ffcaf |
| Datasheet photo 3 | AHID/2d0b76a0dd3a01c648483535df76ec61157940b4 |
| Datasheet photo 4 | AHID/6fd30971639a7a185a689396cb58fd1273dae108 |
| Datasheet photo 5 | AHID/0a5b400e8f017f10e08d6bdab2f539a4a65b0da0 |
| Facet Subcategory | Point of Sale (POS) and Kiosks |
| Facet Series name | HP Engage Flex Pro-C G2 |
| Facet Product type | Point of sales |
| Facet Taxonomy | Point of Sale (POS) Digital signage and Kiosks |
| Facet Form factor | Point of sale |
