Product Description
Overview
- Large-format printing for engineering, architectural, graphic arts and photo professionals.
- Communicate more effectively—no learning curve needed—with print plus scan and copy capabilities
- Immediately update all your partners on project review results with the most compact large-format MFP.[2] Intuitive, convenient print/scan/copy and HP DesignJet print quality help you communicate effectively and move the project forward.
Features
- Anyone can print smoothly from a smartphone or tablet with HP Mobile Printing.[3]
- Enjoy easy installation in the office, construction job site with the most compact large-format MFP.[2]
- Print documents fast—up to 26 seconds for A1/D-size prints.[1]
- No learning curve—with the intuitive design of a single touchscreen, you can scan, copy, and share instantly.
- Share drawings immediately—scan/email from front panel, use HP Smart app[5] to email contacts, post to cloud.
- Easily link your computer, smartphone, or tablet to the printer with Wi-Fi Direct.
- Use built-in scanner to copy and distribute sketches and hand-annotated drawings to peers/partners right away.
- Redesigned stand reduces C02e up to 197 tons/year by units sold.[4]
- Reinforced design and strong legs for easy transport and use at the job site.
- Smart scanning technology protects originals from damage when scanning and obtains precise colors.
- Get HP DesignJet quality also in small-format sizes—print half-size documents with 50-sheet A4/A3 input tray.
- Easily print project sets and PDF documents with HP Click printing software.
Product Videos
Specifications
| Spec | Description |
|---|---|
| Network ready | Standard |
| Connectivity, optional | HP USB 3.0 to Gigabit LAN Adapter |
| Connectivity, standard | Gigabit Ethernet (1000Base-T), Wi-Fi 802.11b/g/n |
| HP ePrint capability | Yes |
| Mobile printing capability | Wi-Fi Direct and local Wi-Fi connectivity to enable mobile printing via HP ePrint, Apple AirPrint™ and HP Smart App. Supports printing from most smartphones and tablets using these operating systems: Android, iOS |
| Finished output handling | Sheet feed, roll feed, input tray, media bin, automatic horizontal cutter |
| UNSPSC code | 43212110 |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Image legal disclaimer | Product image may differ from actual product |
| Product logos | AirPrint; ENERGY STAR; EPEAT; IPv6 Ready Phase 2 (Gold); Mac; Wi-Fi CERTIFIED; Windows 10 Compatible |
| Scan resolution, optical | Up to 600 dpi |
| Enhanced scanning resolution | 600 dpi |
| Linear scan speed | Up to 3.81 cm/sec (color, 200 dpi); Up to 11.43 cm/sec (grayscale, 200 dpi); Up to 1.5 in/sec (color, 200 dpi); Up to 4.5 in/sec (grayscale, 200 dpi) |
| Technology logo, print 1 | Publication logos/energy star Tom apj.JPG |
| Technology logo, print 2 | AHID/7f5fb10b352c00f2fb80593f9113010f5a12d28c |
| Technology logo, print 3 | Publication logos/ipv 6 tom apj.JPG |
| Technology logo, print 4 | Publication logos/mac tom apj.JPG |
| Technology logo, print 5 | Publication logos/wi fi tom apj.JPG |
| Technology logo, print 6 | Publication logos/win 10 tom apj.JPG |
| Print cartridge volume delivered | HP 728 Ink Cartridge: matte black, cyan, magenta, yellow (300 ml); cyan, magenta, yellow (130 ml); matte black (69 ml); cyan, magenta, yellow (40 ml) |
| Color(s) of printing supplies | Cyan, magenta, yellow, matte black |
| Print head nozzles | 1376 |
| Print Technology | Ink |
| Ink drop | 6 pl (C, M, Y); 12.6 pl (mK) |
| Ink types | Dye-based (C, M, Y); pigment-based (mK) |
| Number of print cartridges | 4 (C, M, Y, mK) |
| Print heads | 1 (C, M, Y, mK) |
| Memory | 1 GB |
| Maximum Memory | 1 GB |
| Power consumption | 35 watts (printing), 3.5 watts (sleep), 0.2 watts (standby) |
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1.2 A max |
| What's in the box | HP DesignJet T830 24-in MFP, printhead, ink cartridges, printer stand, spindle, quick reference guide, setup poster, startup software, power cord, refeed preventers |
| Photo (product photo, jpg, 190x170) | Printers and Multifunction/HP-DesignJet-T830-Multifunction-Printer_190x170.jpg |
| Photo (product photo, jpg, 70x100) | Printers and Multifunction/HP-DesignJet-T830-Multifunction-Printer_70x100.jpg |
| Media weight, recommended | 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray) |
| Media width, maximum | 610 mm; 24 in |
| Media sizes, custom | Input tray: 210 x 279 to 330 x 482 mm; Manual feed: 330 x 482 to 610 x 1897 mm; Input tray: 8.3 x 11 to 13 x 19 in; Manual feed: 13 x 19 to 24 x 74.7 in |
| Media sizes supported | Input tray: A4, A3; Manual feed: A2, A1; Input tray: A, B; Manual feed: C, D |
| Media types | Bond and coated paper (bond, coated, heavyweight coated, recycled, plain, bright white), technical paper (natural tracing, vellum), film (clear, matte), photographic paper (satin, gloss, semigloss, premium, polypropylene), self-adhesive (adhesive,... |
| Media thickness (metric) | Up to 0.3 mm |
| Roll maximum weight | 4.1 kg; 9.1 lb |
| Media thickness | Up to 11.8 mil; 0.03 in |
| Supported Primary Applications | Line drawings; Renderings; Presentations |
| Media sizes standard (metric rolls) | 279 to 610 mm |
| Roll external diameter | 100 mm; 3.9 in |
| Roll maximum input | 1 |
| Media sizes standard (sheets, rolls) | 11 to 24 in |
| Package weight | 65.7 kg; 144.8 lb |
| Weight | 46.7 kg; 103 lb |
| Recommended installation method | Professional installation is recommended |
| Sustainable impact specifications | Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; FSC®-certified papers and a range of recyclable HP media with a take-back program; ENERGY STAR® certified; EPEAT® registered |
| Safety | USA and Canada (CSA certified); EU (LVD, EN 60950-1 and EN 62368-1 compliant); Russia (EAC); Singapore (PSB); China (CCC); Mexico (NYCE); Argentina (IRAM); India (BIS) |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC/R&TTE Directives), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI); Certified as Class A product: Korea (KCC) |
| Energy star certified | Yes |
| Environmental certification | ENERGY STAR, EPEAT, CE marking (including RoHS, WEEE, REACH). In compliance with WW RoHS materials restriction requirements in China, Korea, India, Vietnam, Turkey, Serbia, and Ukraine. |
| Eco label | ENERGY STAR® certified; EPEAT registered |
| Software included | HP Click, HP Smart app, HP Support Assistant, HP Print Preview for Windows, HP DesignJet Utility for macOS and Windows |
| Copy resolution (color text and graphics) | Up to 600 x 600 dpi |
| Dynamic security | Dynamic security enabled printer |
| Datasheet photo 1 | AHID/0094b77eb05ee8916a2571e3d2b35639da77976c |
| Datasheet photo 4 | AHID/9a0ca137bd24e5309b9bbdf5c0bf52392989133d |
| Datasheet photo 2 | AHID/9a0ca137bd24e5309b9bbdf5c0bf52392989133d |
| Datasheet photo 3 | AHID/7d0fb4b49f0633ae04488ff7318302a12168033d |
| Acoustic power emissions (active, printing) | 6.5 B(A) (operating), <3.4 B(A) (idle) |
| Acoustic pressure emissions | 48 dB(A) (operating), <16 dB(A) (idle) |
| Operating humidity range | 20 to 80% RH |
| Non-Operating Humidity Range | 0 to 95% RH |
| Operating temperature range | 5 to 40ºC; 41 to 104ºF |
| Storage temperature range | -25 to 55ºC; -13 to 131ºF |
| Manufacturer Warranty | One-year limited warranty. Warranty and support options vary by product, country and local legal requirements. |
| Print speed line drawing (economode, A1 plain paper) | 81 A1 prints per hour |
| Print speed line drawing (economode, D plain paper) | 81 D prints per hour |
| Print speed | 26 sec/page on A1, 81 A1 prints per hour[1]; 26 sec/page on D, 81 D prints per hour[1] |
| Maximum optical density (black) | 8 L* min/2.10 D[3] |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Package dimensions (W x D x H) | 51.6 x 22.4 x 25.4 in; 1310 x 570 x 645 mm |
| Minimum dimensions (W x D x H) | 1098 x 605 x 1155 mm; 43.2 x 23.4 x 45.5 in |
| UPC number | (ABG) 194850951688; (ACJ) 194850951695; (BCD) 194850951701 |
| Non-printable area (cut-sheet) | 5 x 5 x 5 x 5 mm; 0.2 x 0.2 x 0.2 x 0.2 in |
| Non-printable area (roll media) | 5 x 5 x 5 x 5 mm; 0.2 x 0.2 x 0.2 x 0.2 in |
| Theoretical minimum line width | 0.0008 in (HP-GL/2 addressable); 0.02 mm (HP-GL/2 addressable) |
| Printer drivers included | HP-GL/2, HP-RTL drivers for Windows; Raster driver for macOS and Windows |
| Average weekly print volume (D/A1) | 90 A1/D prints per week |
| Functions | Print, copy, scan |
| Printing path | Wi-Fi Direct to enable mobile printing via HP ePrint, Apple AirPrint and HP Smart app for Android and iOS devices, Windows and macOS printer drivers, printing support for Chrome OS, print from USB pen drive |
| Print languages | HP-GL/2, HP-RTL, TIFF, JPEG, CALS G4, URF |
| Model size | 610 mm; 24 in |
| Internal Storage | None |
| Line accuracy | ±0.1%[2] |
| Line accuracy note | ±0.1% of the specified vector length or ±0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A1/D HP Heavyweight media in Best or Normal mode with Original HP inks |
| Guaranteed minimum line width | 0.07 mm (ISO/IEC 13660:2001(E)); 0.0028 in (ISO/IEC 13660:2001(E)) |
| Print time line drawing (economode, A1 plain paper) | 26 sec/page |
| Print time line drawing (economode, D plain paper) | 26 sec/page |
| Scan size, maximum | 610 mm x 2.77 m; 24 x 109 in |
| Scan size, minimum | 203 x 127 mm; 8 x 5 in |
| Scanner type | Sheetfed, CIS (Contact Image Sensor), media jam detection sensor, front feed scanning method |
| Scan file format | JPEG, PDF, TIFF |
| Scan input modes | Scan to email, scan to cloud (through HP Smart app), network, USB, computer, mobile |
| Maximum media thickness | 0.8 mm |
| Bit depth | 24-bit/8-bit |
| Web address for additional information | http://www.hp.com/go/designjett830 |
| Additional information about HP in the countries | http://www.hp.com/uk |
| Additional information about HP | http://www.hp.com |
| Accessories | HP DesignJet 24-in Spindle B3Q36A, HP USB 3.0 to Gigabit LAN Adapter N7P47AA |
| Datasheet publication number | 4AA7-8000EEP |
| Copies, maximum | Up to 99 copies |
| Copy reduce / enlarge settings | 50 to 400% |
| Copier settings | Content type; Lighter/Darker; Background noise removal; Background color removal; Blue print invert; Translucent media; Color; Scan full width (24-in); Auto De-skew; Resize; Copy Margins; Quality |
| Facet Sub brand | DesignJet |
| Facet Subcategory | Large format |
| Facet Product type | Office Printers for CAD and GIS |
| Facet Primary applications | Office documents and presentations; Engineering and construction documents |
| Facet Media size maximum (mm) | 610 |
| Facet Media size maximum (in) | 24 |
| Facet Monthly printed pages | Often |
| Facet Taxonomy | Large Format Printers/ Plotters |
