Product Description
Turn any laptop into a console for headless servers, PCs, ATMs, kiosks and more
The NOTECONS01 KVM Console to USB 2.0 Portable Laptop Crash Cart Adapter turns your notebook or netbook into a portable server crashcart, eliminating the need to lug around a large, heavy and awkward video screen, keyboard, and mouse. This adapter delivers the VGA stream from any host computer to a laptop and emulates the laptop mouse and keyboard outputs for simple access and control of connected servers, PCs or other "headless" devices.
"StarTech.com's USB KVM may be your new best friend for trips to the datacenter... you can use this from the back of the rack. So if you are handling issues that require moving cables or network connections... this can be a major timesaver."
— everythingUSB.com
"The CRN Test Center recommends StarTech's Crash Cart Adapter for any company with a data center or with technicians servicing computers in the field"
— CRN
With portability for the mobile administrator or repair technician in mind, this USB-powered adapter features a small-footprint design that requires no additional accessories to connect to most servers, and requires no server-side software installation. Plus, the pocket-sized adapter draws its power from the server-side USB connections, allowing the laptop/netbook to last longer without consuming battery power.
Ensuring full control of the connected units, the Laptop KVM Server Console Adapter provides immediate access to the POST screen and BIOS, plus the ability to handle full configuration of the attached PC or machine; administrators can connect to a headless server/device without the need of an expensive LCD rackmount console or bulky monitor, keyboard and mouse solution.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
How it works:
The StarTech.com Advantage
- Ultra high resolution support up to 1920 x 1200 @ 60Hz – The highest resolution portable console available
- No power adapter needed - Draws power from the server side USB connection saving your laptop’s battery life, and avoiding the hassle of finding 110V outlets in the server room or remote locations
- Small, ruggedized casing (similar to the size of a cellphone) is easily stored and transported; with no server-side software requirement, you will be up and running in seconds
Features
- Keyboard port type: USB
- Mouse port type: USB
- Video port type: VGA
- Black
Product Videos
Specifications
| Spec | Description |
|---|---|
| Compatible operating systems | Windows® XP, Vista, 7, 8, 8.1, 10, 11 Windows Server® 2008 R2, 2012, 2016, 2019 macOS 10.6 to 10.15, 11.0, 12.0, Mac OS X 13.0 Ventura Linux 2.6.x + |
| Connector 1 | USB Mini-B |
| Connector 1 gender | Female |
| Connector 2 | PS/2 + USB 2.0 A + VGA |
| Connector 2 gender | Male |
| Harmonized System (HS) code | 84733080 |
| Keyboard port type | USB |
| Master (outer) case height | 525mm |
| Master (outer) case length | 520mm |
| Master (outer) case width | 320mm |
| Mouse port type | USB |
| Package depth | 45mm |
| Package height | 160mm |
| Package weight | 400g |
| Package width | 300mm |
| Product colour | Black |
| Products per master (outer) case | 30pc(s) |
| Sustainability certificates | CE, RoHS |
| Sustainability compliance | Yes |
| Video port type | VGA |
| Weight | 170g |
