Product Description
Overview
- Large-format printing for engineering, architectural, graphic arts and photo professionals.
- Read details more clearly and see high-contrast color with new high-definition HP printheads. HP Pixel Control enables smooth gradients, and the integrated vertical trimmer streamlines finishing.[3] Handle complex files and secure your printers/data.
- High-definition prints, fast and secure. More quality with fewer inks.
Features
- Read details more clearly and see high-contrast color with new high-definition HP printheads.
- No need for light inks with HP's dual drop technology.
- Get smooth gradients, even for challenging color combinations, with HP Pixel Control.
- Work with water- and fade-resistant prints, indoors and out, with HP Vivid Photo Inks.[1]
- Handle even the most complex files with powerful processing architecture and the Adobe PDF Print Engine.[2]
- Cut maps to different sizes in fewer steps with the first printer including an integrated vertical trimmer.[3]
- Print up to 20% faster[4] with 2400 nozzle-per-inch, high-definition HP printheads.
- Spend less time on media changes and adjustments with dual roll support and automatic roll switching.[3]
- Protect printers/data from unauthorized access with HP Secure Boot, whitelisting, and encrypted hard disk.
- Protect documents, preserve confidentiality with authentication solutions like PIN printing, card readers.[5]
- Secure your printers with HP JetAdvantage Security Manager; manage your fleet remotely with HP Web Jetadmin.
Product Videos
Specifications
| Spec | Description |
|---|---|
| Network ready | Standard |
| Security features | HP Secure Boot, Whitelisting, Role Based Access Control, SNMPv3, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, Secure Disk erase (DoD 5... |
| Connectivity, standard | Gigabit Ethernet (1000Base-T) (802.3, 802.3u, 802.3ab); Hi-Speed USB 2.0 certified interface for direct printing from USB flash drive |
| Mobile printing capability | Direct print from mobile apps on iOS, Android and Chrome OS; email printing with HP ePrint and HP Smart app for iOS and Android. |
| Finished output handling | Two automatic roll feeds, smart roll-switching, top sheet feed, media output bin, automatic horizontal cutter and vertical trimmer (cuts all HP Z-series printer-qualified media, including most canvas) |
| UNSPSC code | 43212104 |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Product logos | Adobe PostScript 3; Adobe PDF Print Engine 4; ENERGY STAR; EPEAT; Gold IPv6 Ready; HP Pixel Control; Mac; PANTONE Digital Color; Windows 10 Compatible |
| Technology logo, print 5 | AHID/dd10df59ca167ea78eeef7e5b2e698a795b131d7 |
| Technology logo, print 1 | Publication logos/win 10 tom apj.JPG |
| Technology logo, print 3 | Publication logos/ipv 6 tom apj.JPG |
| Technology logo, print 4 | AHID/b504e7ab8574fb23f7819bf5367141da989eb4bc |
| Technology logo, print 2 | Publication logos/mac tom apj.JPG |
| Print Technology | Ink |
| Print cartridge volume delivered | HP 746 Ink Cartridge: cyan, magenta, chromatic red, yellow, matte black, photo black (300 ml) |
| Ink types | Pigment-based |
| Number of print cartridges | 6 (cyan, magenta, yellow, matte black, photo black, chromatic red) |
| Print heads | 3 universal printheads (valid for all colors) |
| Ink drop | 7/3 pl dual-drop weight (M, C, PK); 6 pl single-drop weight (Y, CR, MK) |
| Color(s) of printing supplies | Cyan, magenta, yellow, matte black, photo black, chromatic red |
| Print head nozzles | 2112 per color; 12,672 in total |
| Memory | 128 GB (virtual)[8] |
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max |
| Power consumption | <100 W (printing); <32 W (ready); <6.5 W (sleep); 0.1 W (off) |
| What's in the box | HP DesignJet Z6 PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord |
| Photo (product photo, jpg, 70x100) | Printing and Digital Imaging/c7791e_70x100.jpg |
| Media sizes, custom | 210 x 279 to 1118 x 1676 mm |
| Media sizes supported | A4, A3, A2, A1, A0 |
| Media thickness (metric) | Up to 0.8 mm |
| Media types | Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit |
| Media weight, recommended | 80 to 500 g/m² |
| Media width, maximum | 1118 mm |
| Supported Primary Applications | Banners; Exhibition and event graphics; Light boxes - film; Maps; Orthophotos; Point of sale/display; Posters |
| Roll external diameter | 135 mm |
| Roll maximum input | 2 |
| Roll maximum weight | 13.5 kg |
| Media thickness | Up to 31.5 mil |
| Media sizes standard (metric rolls) | 279 to 1118-mm |
| Recommended media | Q6581A HP Universal Instant-dry Satin Photo Paper (FSC® certified)[10] (Recyclable)[11] 1067 mm x 30.5 m (42 in x 100 ft);E4J57A HP Artist Matte Canvas 1118 mm x 15.2 m (44 in x 50 ft);C6569C HP Heavyweight Coated Paper (FSC® certified)[10] (Recyc... |
| Weight | 96 kg |
| Package weight | 132 kg |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| Energy star certified | Yes |
| Environmental certification | ENERGY STAR; ErP; WEEE; RoHS (EU, China, Korea, India); REACH; EPEAT |
| Safety | USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS) |
| Sustainable impact specifications | 30% post-consumer recycled plastic; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; Highest WIR Print Permanence Ratings in the Industry; Compatible with FSC®-certified HP large format printing materials and HP R... |
| Software included | HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional), HP SmartTracker (optional) |
| Dynamic security | Dynamic security enabled printer |
| Datasheet photo 1 | AHID/386f00864ab94517eb6abbf03460f211018207c5 |
| Acoustic power emissions (active, printing) | 6.3 B(A) (operating), 5.1 B(A) (idle), <3.4 B(A) (sleep) |
| Acoustic pressure emissions | 45 dB(A) (operating), 33 dB(A) (idle), <16 dB(A) (sleep) |
| Operating humidity range | 20 to 80% RH |
| Operating temperature range | 5 to 40ºC |
| Storage temperature range | -25 to 55ºC |
| Manufacturer Warranty | 3 Years Limited Warranty |
| Print speed color image (best, glossy paper) | 9.7 m²/hr[1]; 104 ft²/hr[1] |
| Print speed color image (normal, coated paper) | 18.8 m²/hr[1]; 202 ft²/hr[1] |
| Print speed color image (normal, glossy paper) | 12.9 m²/hr[1]; 139 ft²/hr[1] |
| Print speed | Fast: 80.5 m²/hr on plain media; Normal: 18.8 m²/hr on coated media; Best: 9.7 m²/hr on glossy media[1] |
| Print speed color image (draft, coated paper) | 51.7 m²/hr[1]; 556 ft²/hr[1] |
| Maximum optical density (black) | 4 L* min/2.5 D[7] |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Minimum dimensions (W x D x H) | 1802 x 695 x 998 mm |
| Package dimensions (W x D x H) | 1950 x 766 x 718 mm |
| Non-printable area (cut-sheet) | 5 x 17 x 5 x 5 mm |
| Non-printable area (roll media) | Borderless on all media with V-Trimmer[4] |
| UPC number | (ABA) 194441079913; (ABG) 192018667631; (ACJ) 196068887476; (B19) 192018667600; (BCD) 192018667624 |
| Functions | |
| Theoretical minimum line width | 0.02 mm (PDF addressable @ 1200 dpi) |
| Printer drivers included | Raster and PostScript drivers for Windows and macOS; PDF driver for Windows 8 and above |
| Print languages | Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL |
| Print repeatability | Average < 0.5 dE2000, 95% of colors < 1.4 dE2000[7] |
| Color Stability | < 1 dE2000 in less than 5 minutes[7] |
| Model size | 1118 mm |
| Internal Storage | 500 GB self-encrypting |
| Line accuracy | ±0.1%[5] |
| Guaranteed minimum line width | 0.08 mm (ISO/IEC 13660:2001(E))[6] |
| Printing path | Apple AirPrint, direct printing from USB flash drive, email printing, HP Click, HP driver for macOS, HP driver for Windows, HP driver for Linux, printing support for Chrome OS, HP Print Service Plugin for Android, HP Smart app for iOS and Android,... |
| Additional information about HP in the countries | http://www.hp.com/uk |
| Additional information about HP | http://www.hp.com |
| Web address for additional information | http://www.hp.com/go/designjetZ6 |
| Datasheet publication number | 4AA7-2550EEP |
| Accessories | CN538A HP DesignJet 3-in Core Adapter;G6H51B HP HD Pro 42-in Scanner;G6H50B HP SD Pro 44-in Scanner;N7P47AA HP USB 3.0 to Gigabit LAN Adapter;Q6709A HP DesignJet 44-in Spindle;1QF38A HP DesignJet 44-in Take-up Reel |
| Product long name specifications | HP DesignJet Z6dr 44-in PostScript Printer with V-Trimmer - Print: 85.1 m²/hr; Up to 2400 x 1200 optimized dpi colour; 128 GB (virtual); Ethernet, Fast Ethernet, Gigabit Ethernet, 10/100/1000Base-T Ethernet (802.3, 802.3u, 802.3ab); USB Type-A hos... |
| Facet Subcategory | Large format |
| Facet Product type | High-impact Graphics Printers |
| Facet Sub brand | DesignJet |
| Facet Primary applications | Advertising posters, roll-ups, and banners; Design and illustrations; Maps; Indoor signage; Décor |
| Facet Media size maximum (mm) | 1118 |
| Facet Monthly printed pages | Very frequently |
| Facet Media size maximum (in) | 44 |
| Facet Taxonomy | Large Format Printers/ Plotters |
