Product Description
Overview
- Large-format printing for engineering, architectural, graphic arts and photo professionals.
- Deliver photo-quality prints 2.5 times faster[4] without losing quality. Cut post-processing time up to 20% with the first printer to include an integrated vertical trimmer.[3] Simplify your workflow with new tools in the HP Applications Center.[5]
- Professional photo prints, fast and simple. More quality with fewer inks.
Features
- Get superior gloss uniformity by upgrading your printer to include HP Gloss Enhancer.[2]
- Cut post-processing labor time up to 20% with the first printer to include an integrated vertical trimmer.[3]
- Print up to 2.5 times faster[4] without losing quality, with 2400 nozzle-per-inch high-definition printheads.
- Spend less time on media changes and adjustments with dual roll support and automatic roll switching.[3]
- Easily design applications from posters to banners and canvas with the HP Applications Center.[5]
- No disruption to your workflow, keep using your current RIPs, validated with HP RIP certification program.[6]
- Get remote visibility and control to better manage your print production environment with HP PrintOS.
- Enjoy one-click printing that also helps reduce media waste using HP Click printing software.[7]
- Impress the most demanding customers with smooth transitions and sharp details thanks to HP Pixel Control.
- No need for light inks using new high-definition HP printheads with dual drop technology.
- Achieve expanded gamut with RGB HP Vivid Photo Inks and the embedded spectrophotometer.[1]
Product Videos
Specifications
| Spec | Description |
|---|---|
| Mobile printing capability | Direct print from mobile apps on iOS, Android and Chrome OS; email printing with HP ePrint and HP Smart app for iOS and Android. |
| Network ready | Standard |
| Security features | HP Secure Boot, Whitelisting, Role Based Access Control, SNMPv3, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, Secure Disk erase (DoD 5... |
| Connectivity, standard | Gigabit Ethernet (1000Base-T) (802.3, 802.3u, 802.3ab); Hi-Speed USB 2.0 certified interface for direct printing from USB flash drive |
| UNSPSC code | 43212104 |
| Finished output handling | Roll feed, rear sheet feed, media output bin, automatic horizontal cutter |
| Product logos | Adobe PostScript 3; Adobe PDF Print Engine 4; ENERGY STAR; EPEAT; Gold IPv6 Ready; HP DreamColor Technologies; HP Pixel Control; i1 Color Technology; Mac; PANTONE* Digital Color; Windows 10 Compatible |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Technology logo, print 1 | Publication logos/win 10 tom apj.JPG |
| Technology logo, print 2 | AHID/2f8f66942d9deaefadcb1b41e21cb94f105050b2 |
| Technology logo, print 5 | Publication logos/ipv 6 tom apj.JPG |
| Technology logo, print 6 | AHID/b504e7ab8574fb23f7819bf5367141da989eb4bc |
| Technology logo, print 7 | AHID/dd10df59ca167ea78eeef7e5b2e698a795b131d7 |
| Print heads | 5 universal printheads (valid for all colors) |
| Print cartridge volume delivered | HP 746 Ink Cartridge: cyan, magenta, chromatic red, yellow, matte black, photo black (300 ml); HP 747 Ink Cartridge: chromatic green, chromatic blue, gray (300 ml) |
| Ink drop | 7/3 pl dual-drop weight (M, C, PK, CB, G); 6 pl single-drop weight (Y, CR, MK, CG) |
| Color(s) of printing supplies | Cyan, magenta, yellow, matte black, photo black, chromatic red, chromatic green, chromatic blue, gray |
| Print head nozzles | 2112 per color; 21,120 in total |
| Print Technology | Ink |
| Ink types | Pigment-based |
| Number of print cartridges | 9 (cyan, magenta, yellow, matte black, photo black, chromatic red, chromatic green, chromatic blue, gray), optional gloss enhancer |
| Memory | 128 GB (virtual)[9] |
| Power consumption | <100 W (printing); <32 W (ready); <6.5 W (sleep); 0.1 W (off) |
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max |
| What's in the box | HP DesignJet Z9+ PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord |
| Photo (product photo, jpg, 70x100) | Printing and Digital Imaging/c7791e_70x100.jpg |
| Media sizes supported | A4, A3, A2, A1, A0 |
| Media thickness (metric) | Up to 0.8 mm |
| Media types | Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit |
| Media width, maximum | 1118 mm |
| Media weight, recommended | 80 to 500 g/m² |
| Media sizes, custom | 210 x 279 to 1118 x 1676 mm |
| Weight | 94 kg |
| Package weight | 130 kg |
| Roll external diameter | 135 mm |
| Roll maximum input | 1 |
| Media thickness | Up to 31.5 mil |
| Roll maximum weight | 13.5 kg |
| Supported Primary Applications | Digital fine art; Exhibition and event graphics; Graphics design; Photos; Point of sale/display; Posters |
| Recommended media | Q6581A HP Universal Instant-dry Satin Photo Paper (FSC® certified)[11] (Recyclable)[12] 1067 mm x 30.5 m (42 in x 100 ft);E4J57A HP Artist Matte Canvas 1118 mm x 15.2 m (44 in x 50 ft);C6569C HP Heavyweight Coated Paper (FSC® certified)[11] (Recyc... |
| Media sizes standard (metric rolls) | 210 to 1118-mm wide sheets; 279 to 1118-mm rolls |
| Sustainable impact specifications | 30% post-consumer recycled plastic; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; Highest WIR Print Permanence Ratings in the Industry; Compatible with FSC®-certified HP large format printing materials and HP R... |
| Environmental certification | ENERGY STAR; ErP; WEEE; RoHS (EU, China, Korea, India); REACH; EPEAT |
| Safety | USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS) |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| Energy star certified | Yes |
| Software included | HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional), HP SmartTracker (optional) |
| Dynamic security | Dynamic security enabled printer |
| Datasheet photo 1 | Publication photos/apj z9 tom.jpg |
| Operating humidity range | 20 to 80% RH |
| Acoustic power emissions (active, printing) | 6.0 B(A) (operating), 5.1 B(A) (idle), <3.4 B(A) (sleep) |
| Acoustic pressure emissions | 42 dB(A) (operating), 33 dB(A) (idle), <16 dB(A) (sleep) |
| Operating temperature range | 5 to 40ºC |
| Storage temperature range | -25 to 55ºC |
| Manufacturer Warranty | 3 Years Limited Warranty |
| Print speed color image (best, glossy paper) | 4.5 m²/hr[1]; 48 ft²/hr[1] |
| Print speed color image (normal, coated paper) | 17.2 m²/hr[1]; 185 ft²/hr[1] |
| Print speed color image (normal, glossy paper) | 8.6 m²/hr[1]; 93 ft²/hr[1] |
| Print speed | Fast: 71.4 m²/hr on plain media; Normal: 17.2 m²/hr on coated media; Best: 4.5 m²/hr on glossy media[1] |
| Print speed color image (draft, coated paper) | 50 m²/hr[1]; 538 ft²/hr[1] |
| Maximum optical density (black) | 4 L* min/2.5 D[8] |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Minimum dimensions (W x D x H) | 1802 x 695 x 998 mm |
| Package dimensions (W x D x H) | 1950 x 766 x 718 mm |
| UPC number | (ABA) 194441079944; (ABG) 192018667730; (ACJ) 196068887490; (B19) 192018667709; (B1K) 192018667716; (BCD) 192018667723 |
| Non-printable area (cut-sheet) | 5 x 17 x 5 x 5 mm |
| Non-printable area (roll media) | 5 x 5 x 5 x 5 mm (borderless on selected media[3]) |
| Printing path | Apple AirPrint, direct printing from USB flash drive, email printing, HP Click, HP driver for macOS, HP driver for Windows, HP driver for Linux, printing support for Chrome OS, HP Print Service Plugin for Android, HP Smart app for iOS and Android,... |
| Theoretical minimum line width | 0.02 mm (PDF addressable @ 1200 dpi) |
| Guaranteed minimum line width | 0.08 mm (ISO/IEC 13660:2001(E))[6] |
| Printer drivers included | Raster and PostScript drivers for Windows and macOS; PDF driver for Windows 8 and above |
| Print languages | Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL |
| Print repeatability | Average < 0.5 dE2000, 95% of colors < 1.4 dE2000[8] |
| Functions | |
| Color accuracy | Median < 1.6 dE2000, 95% of colors < 2.8 dE2000[7] |
| Color Stability | < 1 dE2000 in less than 5 minutes[8] |
| Model size | 1118 mm |
| Internal Storage | 500 GB self-encrypting |
| Line accuracy | ±0.1%[5] |
| Web address for additional information | http://www.hp.com/go/designjetZ9 |
| Additional information about HP in the countries | http://www.hp.com/uk |
| Additional information about HP | http://www.hp.com |
| Accessories | CN538A HP DesignJet 3-in Core Adapter;G6H51B HP HD Pro 42-in Scanner;G6H50B HP SD Pro 44-in Scanner;N7P47AA HP USB 3.0 to Gigabit LAN Adapter;Q6709A HP DesignJet 44-in Spindle;1QF38A HP DesignJet 44-in Take-up Reel;2QX55A HP Gloss Enhancer Upgrade... |
| Product long name specifications | HP DesignJet Z9+ 44-in PostScript Printer - Print: 73.9 m²/hr; Up to 2400 x 1200 optimized dpi colour; 128 GB (virtual); Ethernet, Fast Ethernet, Gigabit Ethernet, 10/100/1000Base-T Ethernet (802.3, 802.3u, 802.3ab); USB Type-A host port |
| Facet Subcategory | Large format |
| Facet Product type | Professional Photo-quality Printers |
| Facet Sub brand | DesignJet |
| Facet Primary applications | Advertising posters, roll-ups, and banners; Photo and art; Design and illustrations; Indoor signage; Décor |
| Facet Monthly printed pages | Very frequently |
| Facet Media size maximum (mm) | 1118 |
| Facet Media size maximum (in) | 44 |
| Facet Taxonomy | Large Format Printers/ Plotters |
