Product Description
Overview
- Bringing powerful, intelligently engineered workstations to power users who demand IT that performs – with uncompromising graphics and speed. HP Workstations are easy-to-buy, quick-to-deploy and simple-to-maintain solutions that support businesses, grow with complex needs and anticipate challenges.
- Engineered for demanding graphics and processor intensive applications.
- Full size Z tower power at half the size
- Get all the power of a full size tower at a fraction of the size. Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow—from 3D design to real time ray tracing—now and in the future.
- Re-engineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflows while defying space constraints.
Features
- Accelerate your current workflow with a multitude of options across processor, graphics, memory, storage, and I/O ports with plenty of room to upgrade and expand.
- Design, simulate and real time ray trace on a Z SFF -- FHFL pro graphics and Intel® Core™ processors.
- Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.[3]
- Accelerate your current workflow with options across processor, graphics, memory, storage, and I/O ports.
- Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.[3]
- Design, simulate and—for the first time—real time ray trace on a Z2 SFF. Now fitting full height, full length professional graphics and Intel® processors, this PC delivers tower-sized performance that defies space constraints.
Product Videos
Specifications
| Spec | Description |
|---|---|
| I/O Port location | Front; Rear |
| Wireless | Intel® Wi-Fi 6E AX211 (2x2) and Bluetooth® 5.3 wireless card (supporting gigabit data rate) |
| Wireless supplier | Intel® |
| Wireless Model | Wi-Fi 6E AX211 |
| Wireless standard | Wi-Fi 6E |
| Wireless antenna | 2x2 |
| Bluetooth version | Bluetooth® 5.3 |
| Wireless transfer speeds | Supporting Gigabit data rate |
| Ports | 3 USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; 1 RJ-45; 1 audio-in; 1 audio-out; 1 HP Fiber NIC Port Flex IO; 3 USB Type-A 480Mbps signaling rate; 1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sle... |
| Expansion slots | 1 half-height PCle 4 x16; 1 half-height PCle 3 x4; 1 half-height PCle 3 x4 (x16 connector); 1 half-height PCle 3 x1; 1 full-height PCle 4 x16; 1 full-height PCle 4 x16 (x16 connector) |
| Expansion slots note | 1 M.2 2230 slot for WLAN and 3 M.2 2280 slots for storage |
| UNSPSC code | 43211515 |
| Compatible displays | All HP Z Displays and HP DreamColor Displays are supported. For more information see www.hp.com/go/zdisplays |
| Compatible displays note | Supports 8 displays, driving 8 displays requires the use of integrated and discrete graphics ports. Each source can drive a total of 4 displays. At least one of the integrated graphics ports need to drive two displays in a daisy chain configuration. |
| Image legal disclaimer | Product image may differ from actual product |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Trademark information | Intel, Pentium, the Intel logo, Intel Core, Thunderbolt, vPro, Optane, and Core Inside are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Bluetooth is a trademark of its propr... |
| Processor frequency technology | Intel® Turbo Boost Technology |
| Processor threads | 28 |
| Processor maximum frequency | 5.4 |
| Chipset | Intel® W680 |
| Artificial intelligence | AI Workstation |
| Processor family | Core™ i7; Intel® Core™ i7 14th generation processor |
| Processor maximum frequency uom | GHz |
| Processor Brand | Intel® |
| Processor generation | 14th Generation |
| Processor | Intel® Core™ i7-14700 (up to 5.4 GHz with Intel® Turbo Boost Technology, 33 MB L3 cache, 20 cores, 28 threads) |
| Processor type | Intel Core i7 |
| Processor cache | 33 MB L3 cache |
| Processor core | 16 |
| Processor model | 14700 |
| Segment | Business |
| Subcategory | Workstations |
| Series name | HP Z2 Small Form Factor G9 Workstation |
| Product type | Workstations |
| Sub brand | Z |
| Memory module type | DIMM |
| Number of memory slots | 1 |
| ECC memory | non-ECC |
| Memory speed | 4800 |
| Memory speed uom | MHz |
| Memory and storage | 32 GB memory; 1 TB SSD storage |
| RAM (GB) | 32 |
| Standard memory note | Transfer rates up to 4800 MT/s. |
| Memory | 32 GB DDR5-4800 MHz RAM (1 x 32 GB) |
| Memory layout (slots & size) | 1 x 32 GB |
| Memory size | 32 |
| Memory size uom | GB |
| Memory type | DDR5 |
| Taxonomy | Workstations |
| Usage | Performance computing |
| Storage (GB) | 1000 |
| Power | 450 W 90% efficient, wide-ranging, active PFC |
| Weight | Starting at 5.0 kg |
| Weight note (metric) | Exact weights depend upon configuration (System weight only) |
| Package weight | Starting at 5.9 kg; Starting at 13.1 lb |
| Audio | Realtek ALC3252 |
| Pointing device | HP 125 Wired Mouse |
| Keyboard | HP 125 Wired Keyboard |
| Keyboard connectivity | Wired |
| Management features | HP Client Catalog (download); HP Cloud Recovery; HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager (download); HP BIOS Configuration Utility (download); HP Image As... |
| Software included | HP UWP Pack; Touchpoint Customizer for Commercial; WPS Office; HP Documentation |
| Environmental certification | EPEAT® registered |
| Ecolabels | EPEAT® registered |
| Energy star certified | ENERGY STAR® certified |
| Features | HP 125 Wired Keyboard; HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5; Wi-... |
| Datasheet photo 3 | AHID/09392789547011a6d41d080e3b2e12bf84b0bb53 |
| Datasheet photo 1 | AHID/7aa7ade34235f7fd08e05a91ebf9fcdefe527f12 |
| Datasheet photo 2 | Publication logos/HP_Care_Pack_RGB_blue_icon.jpg |
| Datasheet photo 4 | AHID/d9df44f9ddb47c3e50c83c925670476a32f8ba67 |
| Datasheet photo 5 | AHID/5fe80329d92dba57bbb0f1dba20b48f688e96bb8 |
| Sustainable impact specifications | 80 Plus® Gold power supplies available; 25% ITE-derived closed loop plastic; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; 45% post-consumer recycled plastic; 10% ITE-derived closed loop... |
| Manufacturer Warranty | 3 year (3/3/3) limited warranty includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
| Playbook TS icon memory | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267700.png |
| Playbook TS icon OS | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905482.png |
| Playbook TS icon weight imperial | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c05790117.png |
| Playbook TS icon processor | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201972.png |
| Playbook TS icon connectivity | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201987.png |
| Playbook TS icon storage | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08192819.png |
| Playbook TS icon battery life | http://h10003.www1.hp.com/digmedialib/prodimg/lowres/c03905264.png |
| Playbook TS icon dimensions tower | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08201997.png |
| Playbook TS icon weight metric | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08267650.png |
| Playbook TS icon graphics | https://h10003.www1.hp.com/digmedialib/prodimg/lowres/c08169202.png |
| Operating system | Windows 11 Pro |
| Dimensions (W x D x H) | 38.4 x 30.8 x 10 cm |
| Dimensions (W x D x H) Note | Standard desktop orientation. |
| Package dimensions (W x D x H) | 3.95 x 15.1 x 12.1 in; 10 x 38.4 x 30.8 cm |
| UPC number | 198701611035 |
| Security management | HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5 |
| Form factor | Small form factor |
| Storage capacity uom 01 | TB |
| Internal drive bays | One 2.5" HDD; One 3.5" HDD; Three M.2 NVME 2280 SSD |
| Internal Storage | 1 TB PCIe® Gen4 M.2 SSD |
| Storage controller | Integrated SATA (4 ports 6 Gb/s) with integrated RAID 0, 1, for PCIe SSDs supported. Requires identical hard drives (speeds, capacity, interface). |
| Storage capacity | 1 |
| Storage type 01 | SSD |
| Storage type | SSD |
| External drive bays | One 3.5" HDD; One slim ODD |
| Storage interface 01 | PCIe® Gen 4 |
| Storage form factor 01 | M.2 |
| Graphics | NVIDIA® RTX™ A2000; Discrete |
| Graphics card brand | NVIDIA® |
| Model Number | 2000 |
| Graphics card memory type | GDDR6 |
| Graphics card memory size | 12 |
| Graphics card memory size uom | GB |
| Graphics (discrete) | NVIDIA RTX™ A2000 (12 GB GDDR6 dedicated) |
| Product long name specifications | HP Z2 Small Form Factor G9 Workstation, Windows 11 Pro, Intel® Core™ i7, 32GB RAM, 1TB SSD, NVIDIA® 2000 |
| Product short name specifications | HP Z2 Small Form Factor G9 Workstation, Intel® Core™ i7, 32GB RAM, 1TB SSD |
| Facet Segment | Business |
| Facet Subcategory | Workstations |
| Facet Series name | HP Z2 Small Form Factor G9 Workstation |
| Facet Product type | Workstations |
| Facet Sub brand | Z |
| Facet Artificial intelligence | AI Workstation |
| Facet Processor generation | 14th Generation |
| Facet Processor type | Intel Core i7 |
| Facet RAM (GB) | 32 |
| Facet Taxonomy | Workstations |
| Facet Usage | Performance computing |
| Facet Storage (GB) | 1000 |
| Facet Environmental certification | EPEAT® registered |
| Facet Operating system | Windows 11 Pro |
| Facet Features | HP 125 Wired Keyboard; HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5; Wi-... |
| Facet Graphics | NVIDIA® RTX™ A2000 |
| Facet Ports | 1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge); 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack, 3 USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; ... |
| Facet Form factor | Small form factor |
