Product Description
Overview
Features
Product Videos
Specifications
| Spec | Description |
|---|---|
| Security features | HP Secure Boot, Whitelisting, Role Based Access Control, SNMPv3, HTTPS, Secure-IPP, IPsec/Firewall, Certificates management, 802.1X, TLS 1.0/1.1/1.2, HP Web Jetadmin compatible, HP JetAdvantage Security Manager compatible, Secure Disk erase (DoD 5... |
| Network ready | Standard |
| Connectivity, standard | Gigabit Ethernet (1000Base-T) (802.3, 802.3u, 802.3ab); Hi-Speed USB 2.0 certified interface for direct printing from USB flash drive |
| Mobile printing capability | Direct print from mobile apps on iOS, Android and Chrome OS; email printing with HP ePrint and HP Smart app for iOS and Android. |
| Finished output handling | Roll feed, rear sheet feed, media output bin, automatic horizontal cutter |
| UNSPSC code | 43211612 |
| Copyright notice | The product could differ from the images shown. © 2014 Hewlett-Packard Development Company, L.P. The Information contained herein is subject to change without notice. Warranties for HP products and services are set out in the express warranty stat... |
| Image legal disclaimer | Product image may differ from actual product |
| Product logos | Adobe PostScript 3; Adobe PDF Print Engine 4; ENERGY STAR; EPEAT; Gold IPv6 Ready; HP Pixel Control; Mac; PANTONE Digital Color; Windows 10 Compatible |
| Technology logo, print 2 | Publication logos/mac tom apj.JPG |
| Technology logo, print 1 | Publication logos/win 10 tom apj.JPG |
| Technology logo, print 3 | Publication logos/ipv 6 tom apj.JPG |
| Technology logo, print 4 | AHID/b504e7ab8574fb23f7819bf5367141da989eb4bc |
| Technology logo, print 5 | AHID/dd10df59ca167ea78eeef7e5b2e698a795b131d7 |
| Ink types | Pigment-based |
| Number of print cartridges | 6 (cyan, magenta, yellow, matte black, photo black, chromatic red) |
| Print heads | 3 universal printheads (valid for all colors) |
| Print cartridge volume delivered | HP 746 Ink Cartridge: cyan, magenta, chromatic red, yellow, matte black, photo black (300 ml) |
| Color(s) of printing supplies | Cyan, magenta, yellow, matte black, photo black, chromatic red |
| Print Technology | Ink |
| Ink drop | 7/3 pl dual-drop weight (M, C, PK); 6 pl single-drop weight (Y, CR, MK) |
| Print head nozzles | 2112 per color; 12,672 in total |
| Memory | 128 GB (virtual)[8] |
| Power consumption | <100 W (printing); <32 W (ready); <6.5 W (sleep); 0.1 W (off) |
| Power | Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 2 A max |
| What's in the box | HP DesignJet Z6 PostScript Printer, printheads, introductory ink cartridges, printer stand and media bin, spindle, 3-in core adapter, quick reference guide, setup poster, power cord |
| Photo (product photo, jpg, 70x100) | Printing and Digital Imaging/c7791e_70x100.jpg |
| Media types | Photographic, fine art printing material, self-adhesive, banner and sign, bond and coated, backlit |
| Media thickness (metric) | Up to 0.8 mm |
| Media sizes supported | A4, A3, A2, A1, A0 |
| Media sizes, custom | 210 x 279 to 1118 x 1676 mm |
| Media width, maximum | 1118 mm |
| Media weight, recommended | 80 to 500 g/m² |
| Recommended media | Q6581A HP Universal Instant-dry Satin Photo Paper (FSC® certified)[10] (Recyclable)[11] 1067 mm x 30.5 m (42 in x 100 ft);E4J57A HP Artist Matte Canvas 1118 mm x 15.2 m (44 in x 50 ft);C6569C HP Heavyweight Coated Paper (FSC® certified)[10] (Recyc... |
| Media sizes standard (metric rolls) | 279 to 1118-mm |
| Supported Primary Applications | Banners; Exhibition and event graphics; Light boxes - film; Maps; Orthophotos; Point of sale/display; Posters |
| Roll external diameter | 135 mm |
| Roll maximum input | 1 |
| Roll maximum weight | 13.5 kg |
| Media thickness | Up to 31.5 mil |
| Weight | 86 kg |
| Package weight | 123 kg |
| Electromagnetic compatibility | Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES), EU (EMC Directive), Australia (ACMA), New Zealand (RSM), China (CCC), Japan (VCCI), Korea (KCC), South Africa (SABS) |
| Energy star certified | Yes |
| Environmental certification | ENERGY STAR; ErP; WEEE; RoHS (EU, China, Korea, India); REACH; EPEAT |
| Safety | USA and Canada (CSA certified); EU (LVD and EN 60950-1 compliant); Russia, Belarus, Khazakstan (EAC); Singapore (PSB); China (CCC); Argentina (IRAM); India (BIS) |
| Sustainable impact specifications | 30% post-consumer recycled plastic; Free, convenient HP ink cartridge and printhead recycling with HP Planet Partners; Highest WIR Print Permanence Ratings in the Industry; Compatible with FSC®-certified HP large format printing materials and HP R... |
| Software included | HP Click printing software, HP PrintOS, HP Web Jetadmin, HP DesignJet Utility including HP Color Center, HP Partner Link, HP JetAdvantage Security Manager (optional), HP SmartStream (optional), HP SmartTracker (optional) |
| Dynamic security | Dynamic security enabled printer |
| Datasheet photo 1 | AHID/386f00864ab94517eb6abbf03460f211018207c5 |
| Operating humidity range | 20 to 80% RH |
| Operating temperature range | 5 to 40ºC |
| Storage temperature range | -25 to 55ºC |
| Acoustic power emissions (active, printing) | 6.0 B(A) (operating), 5.1 B(A) (idle), <3.4 B(A) (sleep) |
| Acoustic pressure emissions | 42 dB(A) (operating), 33 dB(A) (idle), <16 dB(A) (sleep) |
| Manufacturer Warranty | One-year limited hardware warranty |
| Print speed color image (draft, coated paper) | 556 ft²/hr[1]; 51.7 m²/hr[1] |
| Print speed color image (best, glossy paper) | 9.7 m²/hr[1]; 104 ft²/hr[1] |
| Print speed color image (normal, coated paper) | 18.8 m²/hr[1]; 202 ft²/hr[1] |
| Print speed color image (normal, glossy paper) | 12.9 m²/hr[1]; 139 ft²/hr[1] |
| Print speed | Fast: 80.5 m²/hr on plain media; Normal: 18.8 m²/hr on coated media; Best: 9.7 m²/hr on glossy media[1] |
| Maximum optical density (black) | 4 L* min/2.5 D[7] |
| Print quality color (best) | Up to 2400 x 1200 optimized dpi |
| Minimum dimensions (W x D x H) | 1802 x 695 x 998 mm |
| Package dimensions (W x D x H) | 1950 x 766 x 718 mm |
| Non-printable area (cut-sheet) | 5 x 17 x 5 x 5 mm |
| Non-printable area (roll media) | 5 x 5 x 5 x 5 mm (borderless on selected media[3]) |
| UPC number | 193015737198 |
| Color Stability | < 1 dE2000 in less than 5 minutes[7] |
| Functions | |
| Theoretical minimum line width | 0.02 mm (PDF addressable @ 1200 dpi) |
| Model size | 1118 mm |
| Internal Storage | 500 GB self-encrypting |
| Line accuracy | ±0.1%[5] |
| Guaranteed minimum line width | 0.08 mm (ISO/IEC 13660:2001(E))[6] |
| Print repeatability | Average < 0.5 dE2000, 95% of colors < 1.4 dE2000[7] |
| Printer drivers included | Raster and PostScript drivers for Windows and macOS; PDF driver for Windows 8 and above |
| Print languages | Adobe PostScript 3, Adobe PDF 1.7, TIFF, JPEG, CALS G4, HP-GL/2, HP-RTL |
| Printing path | Apple AirPrint, direct printing from USB flash drive, email printing, HP Click, HP driver for macOS, HP driver for Windows, HP driver for Linux, printing support for Chrome OS, HP Print Service Plugin for Android, HP Smart app for iOS and Android,... |
| Additional information about HP in the countries | http://www.hp.com/uk |
| Additional information about HP | http://www.hp.com |
| Web address for additional information | http://www.hp.com/go/designjetZ6 |
| Datasheet publication number | 4AA7-2550EEP |
| Accessories | CN538A HP DesignJet 3-in Core Adapter;G6H51B HP HD Pro 42-in Scanner;G6H50B HP SD Pro 44-in Scanner;N7P47AA HP USB 3.0 to Gigabit LAN Adapter;Q6709A HP DesignJet 44-in Spindle;1QF38A HP DesignJet 44-in Take-up Reel |
| Facet Product type | High-impact Graphics Printers |
| Facet Sub brand | DesignJet |
| Facet Subcategory | Large format |
| Facet Primary applications | Advertising posters, roll-ups, and banners; Design and illustrations; Maps; Indoor signage; Décor |
| Facet Media size maximum (mm) | 1118 |
| Facet Media size maximum (in) | 44 |
| Facet Monthly printed pages | Very frequently |
| Facet Taxonomy | Large Format Printers/ Plotters |
